High Speed, High-Low Temperature Tensile Testing Machine
| FOB Price: | 1.00 - 2.00 USD/Set |
|---|---|
| Supply Ability: | 360 Set(s) per Year |
| Shipping: | Tianjin |
| Payment Terms: | L/C, D/A, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | wooden case |
Quick Details
- Usage: Universal Testing Machine
- Power: Electronic
- Model Number: HST6-D-HLT
- Brand Name: HRJ
Specifications
Introduction
L High speed and high-low temperature testing system is used to test and research with material, parts, component, constructural part, which made of metal, nonmetal, alloy, composite material, for high speed, high speed and high-low temperature environmental test.
L test for property of variety of textile, food, medcine, cosmetic, rubber, plastic, film, biology material.
L tensile, peeling, and welding strength test with electronic part.
L peeling, bending strength, fastening property test with printing circuit board.
L tensile test with wooden, paper, film production
L stress relaxation and adhesive strength test.
L high speed and high-low temperature tensile, compression, recycle tensile, tensile-tensile, tensile-compression test.
Important specification:
Loading capacity
100N, 200N, 500N, 1000N, 2000N, 5KN, 10KN, 20KN, 50KN, 100KN
Test speed
0.0001~600mm/min(240in/min)(100mm/s)
Grade of speed
0.0001~6000mm/min (self-set in range)
Starting time of tensile
0~6000mm/min/1.0s
Stopping time of tensile
6000mm/min~0/1.0s
Precision of high speed
±0.2%
Resolution of position for high speed
0.033μm
Controlling precision of position for high speed
±0.2%
Precision of loading
±0.5% of displaying value
Gathering frequency
1000Hz(self-setting point between 10Hz and 1000Hz)
High-low and high temperature environmental test chamber:
L range of controlling temperature for high temperature: RT+10℃~2200℃
L grade of high temperature: RT+10℃~100℃, ~300℃,~600℃, ~800℃, ~1000℃, ~1200℃, ~1600℃, ~1800℃, ~2200℃.
L range of controlling temperature for low temperature:-100℃~RT
L grade of low temperature: -10℃, -25℃,-40℃,-55℃, -65℃, -80℃, -85℃, -90℃.
L variety of structural type: opposite opening cyliner, square moving type, rotating rise and fall type, combining type.
L rising and falling adjustable supporting frame, moving adjustable supporting frame, revolving supporting frame, combining supporting frame.
L intellegent PID temperature controlling and adjusting regulator, temperature is not overshoot with fluctuation.
