Wuhan Darppon Medical Technology Co., Ltd.
China Manufacturer with main products: B Mode Ultrasound Scanner, Human B Ultrasound Scanner, Human Color Doppler, Veterinary B Ultrasound Scan, Veterinary Sperm Analyzer,... |
12.1 inch multi parameter patient monitor price Mars-B
| FOB Price: | 1,500.00 - 2,000.00 USD/Piece |
|---|---|
| Supply Ability: | 5,000 Piece(s) per Month |
| Shipping: | standard export package |
| Payment Terms: | L/C, T/T, Western Union |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hubei in China |
| Packaging Details: | standard export package |
Quick Details
- Model Number: Mars-B
- Brand Name: darppom
- Type: Doppler Ultrasound Equipment
- Type: ECGmachine, Maternal-Neonatal Ultrasonic Monitor
- Brand Name: Darppon
- Dimension: 360mm*310mm*120mm
- Display: 12.1" color LED
- Transducer type: 12-Crystal ultrasound transducer
- Measure method: Wide beam pulse doppler
Specifications
12.1 inch multi parameter patient monitor price Mars-B
Features
Newly advanced A8 main board with Linux OS, more stable and safe,
the calculating speed is 4 times faster than traditional products
Foldable 12.1 inches high-brightness LED display, touch screen (optional)
12-Crystal doppler transducer for accurate detection (waterproof for option)
Supporting operation with keyboard and mouse (optional)
Large capacity storage space, 8640 hours memory for fetal traces
Support medical history search by patient ID, name and mobile number
FHR signal quality indicator helps optimize the probe position
On-screen scrolling for viewing stored fetal traces
Configurable audible and flashing fetal heart rate alarms
Cross-Channel Verification (CCV) detects coincidence between all fetal and maternal heart/ pulse rates
Supporting Multi-display mode to meet different clinical requirement, including Fetal-parameter
interface, Maternal-parameter interface, Fetal/Maternal-parameter interface, big font,
alarm review, ECG review, trend table, trend graph and OxyCRG display
NIBP self-test mode: including overpressure test, static pressure test and air leakage test.
Built-in high speed thermal printer, printing width can be selectable to 112mm,150mm
Internal rechargeable Li-ion battery or AC power from external power supply
Optional build-in wireless network card, supporting wired or wireless connection to the central monitoring station
Optional Fischer Non-Stress Test (NST) report software allows interpretation of fetal heart rate and TOCO traces,
and generates a printed report automatically for a reassuring NST
Support HL7 (Health Level Seven, optional)
Dimension and Weight
- Dimension: 360mm*310mm*120mm
- Weight: 5.3kg(excluding accessories)
Power Supply
- Voltage:AC100~240V, 50/60HZ
Display
- 12.1" color LED (0-90° rotation)
- Resolution:1024*768 pixels
| Method | Thermal printer |
| Paper | Z-fold, thermosensitive |
| Paper width | 112 mm(4.41 in)/150 mm(5.91 in) |
| Printing speed | 1/2/3cm/min |
| Trace | Max. 4 tracks |
| Real-time Recording, | Recording way |
| Type | Rechargeable lithium battery 14.8V/2200mAh |
| Charge Cycle | ≥500 times |
| Working time | 2 hours (optional larger battery for 4-5 hrs) |
| Weight | 5.3kg(excluding accessories) |
