WC67Y CNC Hydralic Bending Machine

FOB Price:	11,900.00 - 18,500.00 USD/Set
Supply Ability:	150 Set(s) per Month
Shipping:	Stock
Payment Terms:	L/C, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China
Packaging Details:	Naked Package/ Plywood Case

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Extra Services: Machining
Automation: Automatic
Power: Hydraulic
Material / Metal Processed: Stainless Steel
Machine Type: Beading Machine
Model Number: WC67Y
Brand Name: TMA Machine
Condition: New

Specifications

Product Details:

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Nanjing, Jiangsu in China
Packaging Details:	Naked Package/ Plywood Case

Quick Details

· Condition: New

· Brand Name: TMA Machine

· Machine Type: Beading Machine

· Raw Material: Sheet / Plate Rolling

· Material / Metal Processed: Stainless Steel

· Power: Hydraulic

· Automation: Automatic

· Certification: CE

· After-sales Service Provided: Engineers available to service machinery overseas

Specifications

Descriptions of CNC Metal Bending Machine:

■ Totally European design, streamlined looking, Monoblock, Welded steel frame rigid to deflection moment and high tensile with ST44 A1 material.

■ AccruL PRESS BRAKE incorporates ESTUN E10 controls offer not only failsafe operation of the vital operations of the machine, but also offer the operator considerable assistance in carrying out the entire bending process.

■ This type of metal machining tool is a kind of steel torsion bar synchro press brake. Electronic control of back gauge and ram stroke, data displayed and manual setting.

■ Adopt integrated hydraulic control system, more reliable and easy for maintenance. Hydraulic system is from Bosch – Rexroth, Germany.

■ All seals in cylinder is PARKER from USA, the most famous brand, good quality and high performance

■ Electrical panel with cooling system designed to meet CE Standards and composed of automation and electrical equipments with SIEMENS brand

■ Protective fence and the safety interlock to ensure the operation safety. Have a movable single-hand pedal switch, easy to operate.

■ Front Side Covers with safety switches, Back light safety guards (Category-4), Foot pedal conforming to CE regulation.

■ The machine by the European Union CE certification and ISO quality system certification
Technical Specification:

Model (WC67Y)	Nominal Pressure (kN)	Length of table (mm)	Distance Between Housing (mm)	Throat Depth (mm)	Stroke (mm)	Open Hight (mm)	Main Motor (kW)	Dimensions (L x W x H) (mm)	weight (T)
40/2000	400	2000	1600	200	110	335	4	2545x1510x2050	3
40/2500	400	2500	2000	200	110	335	4	2950x1510x2080	3.5
63/2000	630	2000	1600	250	110	350	5.5	2555x1600x2130	3.8
63/2500	630	2500	2000	250	110	350	5.5	2960x1600x2180	4.2
63/3200	630	3200	2600	250	110	350	5.5	3740x1600x2230	5.2
100/2500	1000	2500	2000	350	150	400	7.5	2980x1650x2330	6.3
100/3200	1000	3200	2600	350	150	400	7.5	3740x1650x2355	7
100/4000	1000	4000	3200	350	150	400	7.5	4550x1650x2450	8.8
100/5000	1000	5000	4000	350	150	400	7.5	5100x1500x2650	11.8
125/2500	1250	2500	2000	350	150	410	7.5	3980x1650x2370	7.5
125/3200	1250	3200	2600	350	150	410	7.5	3750x1650x2450	8.2
125/4000	1250	4000	3200	350	150	410	7.5	4550x1650x2470	9
125/5000	1250	5000	4000	350	150	410	7.5	5100x1500x2795	11.5
125/6000	1250	6000	4500	350	150	410	7.5	6100x1500x2895	14
160/2500	1600	2500	2000	350	150	425	11	2980x1715x2410	8.5
160/3200	1600	3200	2550	350	150	425	11	3750x1715x2450	11
160/4000	1600	4000	3200	350	190	450	11	4550x1715x2730	12
160/5000	1600	5000	4000	350	190	450	11	5100x1570x2900	15.5
160/6000	1600	6000	4500	350	190	450	11	6100x1570x3010	19
200/3200	2000	3200	2600	350	240	460	11	3750x1815x2715	13
200/4000	2000	4000	3200	350	240	460	11	4550x1815x2850	14
200/5000	2000	5000	3800	350	240	460	11	5100x1715x3020	18.5
200/6000	2000	6000	4500	350	240	460	11	6100x1715x3120	21
250/3200	2500	3200	2600	400	240	525	11	3750x2010x2850	15.5
250/4000	2500	4000	3200	400	240	525	11	4550x2010x3010	17
250/5000	2500	5000	3800	400	240	525	11	5100x1890x3190	21.5
250/6000	2500	6000	4500	400	240	525	11	6100x1890x3350	28
300/3200	3000	3200	2600	400	250	545	15	3740x2100x3235	19.5
300/4000	3000	4000	3200	400	250	545	15	4340x2100x3300	22
300/5000	3000	5000	3800	400	250	545	15	5100x2100x3430	26
300/6000	3000	6000	4500	400	250	545	15	6100x2100x3490	29

WC67Y CNC Hydralic Press Brake
