Multi Heads CO2 Fabric Laser Cutting Machine for Garment

FOB Price:	3,000.00 - 5,000.00 USD/Set
Supply Ability:	300 Set(s) per Month
Shipping:	7 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

In Stock

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	Plywood case

Quick Details

Application: Laser Cutting
After-sales Service Provided: Engineers available to service machinery overseas
Certification: CE,SGS,FDA BV
Model Number: SUNY-1610T
Brand Name: SUNYLASER
Graphic Format Supported: AI,BMP,DST,DWG,DXF,DXP,LAS,PLT,
Control Software: Sunylaser software
Cooling Mode: Water Cooling
CNC or Not: Yes
Cutting Speed: 0-800mm/s
Cutting Area: 1600*1000mm
Cutting Thickness: 50mm
Applicable Material: Acrylic,Crytal,Glass,Leather,MDF,Paper,plastic,Plexiglax,Plywood,Rubber,Stone,Wood,
Laser Type: CO2
Condition: New
HS code: 8456100090

Specifications:

Control system:	DSP control system
Laser type:	Sealed CO2 glass laser tube
Working area:	16001000mm(62.9939.37inch)
Work platform:	Honeycomb platform
Laser power:	60w/80w/100w/130w/150w
Pass-thru doors:	Allow to cut extremely long materials(max thickness 40mm)
Interface:	USB connection ( Work in Windows XP, 2000,Vista,7)
Memory:	64Mb Buffer Memory
Driver system:	Stepper motor
Auxiliary equipments:	Exhaust-fan, air-exhaust pipe
Laser Tube life hours:	10000 Hours
Repeating precision:	±0.05mm
Moving system:	CNC controlling units
Cooling mode:	Water-cooling and protection system
Max speed:	600mm/s for engraving, 300mm/s for cutting
Working voltage:	AC110/220±10% 50/60Hz
Whole power:	<1250W
Operating temperature:	0-45°C(32° - 113° F)
Operating humidity:	5%-95%
Controlling software:	Original sunylaser software
Graphic format supported:	BMP,PLT,AI,DXF,DST,JPG,CDR,HPGL,PNG,DSB,GIF,MNG, TIF,TGA,PCX,JP2, JPC,PGX,RAS,PNM,SKA,RAW etc
Compatible software:	Auto CAD, CoreIDraw X2/X3/X4, photoshop etc
Resolution:	4000DPI
Machine dimension:	215015601150mm
Packing dimension:	224016001290mm
Net weight:	320kg
Gross weight:	400kg
Packing:	Plywood case

Standard accessories:

1) 2×Air pumps/compressors for Air Assist ( for blowing off debris as the laser engrave or cut)

2) 1×Exhaust fans/Blower with Tube ducts (install inside machine)

3) 2×Industrial chillers

4) 2×Water protections(make sure the water cycle is normal)

5) 1×USB Cable (connecting PC and laser)

6) 1×DVD (including software, user manual, guiding videos etc)

7) 2×Power cables

8) 1×Tool box
