Stationary Scissor Lift Tables Car Hydraulic Electric Lift
| Supply Ability: | 5,000 Set(s) per Year |
|---|---|
| Shipping: | Qingdao, China |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | Iron case or plywood case package |
Quick Details
- Certification: CE, TUV, SGS
- Max. Lifting Height: 3000mm
- Rated Loading Capacity: 3000kg
- Lift Drive / Actuation: Hydraulic
- Brand Name: SDLIFT
- After-sales Service Provided: Engineers available to service machinery overseas
- Warranty: 24 Months
- Weight: 4800kg
- Overall Dimensions: 2800*3000*1000mm
- Table Size: 2600*2800mm
- Min. Lifting Height: 800mm
- Power: 220v, 240v, 380v or as clients requests
- Lift Mechanism: Scissor Lift
- Model Number: SJG3-3
- Type: Double Cylinder Hydraulic Lift
- Design: Scissor
- power: 220v, 240v, 380v or other
- install: underground
- Color: Red, Grey, Yellow, Blue, Or As Your Optional
- Motor: customer required brand or Chinese famous brand
Specifications
Application:
- the electric car lift can be used to lift car with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor.
- Operation is easy. There are 2 sets control system installed on the electric car lift, 1 control box below, and 1 hand controller on safety rail that can be operated on work platform.
Configuration:
1) Lift height: 3m
2) Lift loading capacity: 3T
3) Lift platform size: 5.5m*2.6m
4) Platform Material:rectangular tube + checkered iron
5) Scissor material: high strength Manganese Steel.
6) Hydraulic system: as your requests.
7) High Precision Hydraulic Cylinder.
8) Piston Rod: hard chromium plating surface.
9) High-pressure oil pump
10) Hydraulic oil: summer 46#, winter 32#
11) Controller: 1 control box below, 1 control panel above platform
the frequent models we supplied for our clients:
MODEL |
LOAD CAPACITY |
PLATFORM SIZE |
LIFT HEIGHT |
PIT DEPTH |
POWER |
SJG2.5-3 |
2.5T |
5.2m x 2.6m |
3m |
750mm |
220V, 240V, 380V or 400V |
SJG2-6.5 |
2T |
5.2m x 2.8m |
6.5m |
800mm |
220V, 240V, 380V or 400V |
SJG2.5-3.5 |
2.5T |
5.2m x 2.6m |
3.5m |
800mm |
220V, 240V, 380V or 400V |
SJG2.5-5 |
2.5T |
5.6m x 3m |
5m |
800mm |
220V, 240V, 380V or 400V |
SJG3-2.5 |
3T |
5m x 2.3m |
2.5m |
750mm |
220V, 240V, 380V or 400V |
SJG3-3 |
3T |
5.2m x 2.6m |
3m |
800mm |
220V, 240V, 380V or 400V |
SJG3-3.5 |
3T |
5.6m x 2.7m |
3.5m |
800mm |
220V, 240V, 380V or 400V |
SJG5-10 |
5T |
4.5m x 2.5m |
10m |
1150mm |
220V, 240V, 380V or 400V |
SJG8-2.5 |
8T |
6.5m x 4.5m |
2.5m |
850mm |
220V, 240V, 380V or 400V |
SJG12-3 |
12T |
5.5m x 2.8m |
3m |
950mm |
220V, 240V, 380V or 400V |
SJG15-4.5 |
15T |
8m x 2.2m |
4.5m |
1150mm |
220V, 240V, 380V or 400V |
SJG20-5 |
20T |
6m x 3m |
5m |
1200mm |
220V, 240V, 380V or 400V |
the Electric car lift Can be customized as your detailed size, Our car lift is customized for every clients. | |||||
Parts showing:
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) the safety rails to guarantee safety of the cars above the platform.
3) the limit switch system helps electric car lift to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the electric car lift Are passed 1.2 times loading test before leaving factory.
Our services:
1) We can design the customerized electric car lift as per your requirement.
2) the most suitable electric car lift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) Two year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9)We could reply you in 2 hours after received your any questions even on weekend and holiday. Engineers are available to your country if necessary.
