Tysim Piling Equipment Co., Ltd.
China Manufacturer with main products: Rotary Drilling Rig, Hydraulic Pile Breaker, Telescopic Boom, Rotary Bored Piles, Rotary Pile Rig, Diaphragm Wall Grab, Hydraulic Auger,... |
High Efficiency Rotary Bored Pile Drilling Rig KR80A
| Supply Ability: | 5 Set(s) per Month |
|---|---|
| Shipping: | 30days after receiving the down payment |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | One is nude packing and overall transport by sea with roll-on-roll-off ship. |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Brand Name: Tysim
- Power Type: Diesel
- Type: Rotary Drilling Rig
- Condition: New
- Warranty: 2000Hours or one year
- Certification: CE, ISO9001
- Model Number: KR80A
- Max torque: 80kN.m
- Max drilling diameter: 1000mm
- Max drilling depth: 22m/28m
Specifications
Specifications
1 Pile drilling machine KR80A is small sized pile machinery by TYSIM designed.
2 Leading the overall transport Full Hydraulic and can change transport state into working state rapidly.
3 Use an imported Cummins B3.9-C electrical fuel injection turbo engine (EUIII).
4 High performance hydraulic system and components from international brands.
5 after-sale service is simple, with low failure rate.
6 Makes the money for you and completes the construction requirements.
7 Low noise and emissions.
8 High-performance hydraulic system and control system that guarantee efficiency.
Technical specification
| Torque | 80 kN.M |
| Max. diameter | 1000 mm |
| Max. drilling depth | 22 m/28 m |
| Speed of rotation | 8~30 rpm |
| Max. crowd pressure | 80 kN |
| Max. crowd pull | 120 kN |
| Main winch line pull | 80 kN |
| Main winch line speed | 72 m/min |
| Auxiliary winch line pull | 35 kN |
| Auxiliary winch line speed | 40 m/min |
| Stroke(crowd system) | 2000 mm/3500mm |
| Mast inclination(lateral) | 3 |
| Mast inclination(forward) | 4 |
| Max. operating pressure | 34.3 MPa |
| Pilot pressure | 3.9 MPa |
| Travel speed | 2.8 km/h |
| Traction force | 98 kN |
| Operating height | 12580 mm |
| Operating width | 2700 mm |
| Transport height | 3250 mm |
| Transport width | 2700 mm |
| Transport length | 9150 mm |
| Overall weight | 24 t |
