JK1530 Speaker Amplifier USB Decoder Recorder Bluetooth MP3 Module Circuit Board

FOB Price: 1.00 - 6.00 USD/Piece
Supply Ability: 20,000,000 Piece(s) per Month
Shipping: EXW SHENZHEN
Payment Terms: T/T, Western Union, MoneyGram
Update Time: 2017/11/6
In Stock
  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China
Packaging Details: sd bluetooth usb fm radio tuner mp3 audio kit with ir remote control:340PCS/CT, 11.5KG,Size:57*31*22

Quick Details

  • Operating Temperature: Normal
  • Supply Voltage: dc12v/dc5v
  • Application: Pro audio, Amplifier,Speaker,car audio...
  • Type: Logic ICs
  • Brand Name: Speaker amplifier usb decoder recorder bluetooth mp3 module circuit
  • Dissipation Power: amplifier speaker power
  • Model Number: JK1530
  • Product type: MP3 decoder board
  • Application: Pro audio, Amplifier,Speaker,car audio...
  • Format: MP3/ WMA /WAV
  • Memory: USB/SD
  • Function: USB/SD/MP3/FM/Bluetooth/Recorder /Line
  • Support: IR remote control
  • Display: LCD Display
  • size: 110*49 mm
  • Voltage: 5V/12V
  • Product name: Speaker amplifier usb decoder recorder bluetooth mp3 module circuit board

Specifications

 JK1530 Speaker amplifier usb decoder recorder bluetooth mp3 module circuit board

 1.Speaker amplifier usb decoder recorder bluetooth mp3 module circuit board function.

  USB/SD /MP3/Line in (AUX)/FM/

  Support  Bluetooth

  Play music, support SD card and U disk, support MP3/WMA/WAV, support to play higher bit rate by 1410 Kbps songs.

  Recording function supports the highest bit rate for 192 Kbps,recorder format WAV

  Formarts :WMA / WAV  / MP3

  MP3 decorder support 32–320kbps

  FAT16 or FAT32 systems supported

  6 Keys: MODE, PLAY/PAUSE , STOP , REPEAT , PRE , NEXT,

 With Remote control

 2, Keys function:



MODE: USB/SD /FM / Line in Bluetooth /Recorder switch., In Line in mode : Long press MODE for recorder


NEXT : Under USB /SD /Bluetooth mode,  short press : NEXT; long press : Fast forward (Bluetooth mode no valid )
             Under FM mode, short press to selection up., long press : Backward search radio.


PLAY/PAUSE:Under USB /SD /Bluetooth mode, PAUSE ;

             Under AUX mode, press play/mute.
             Under FM mode, short press to automatic selection.


PRE : Under USB /SD /Bluetooth mode,  short press : PRE; long press : Fast forward (Bluetooth mode no valid )
            Under FM mode, short press to selection down, long press : Forward search Radio



REPEAT : Under USB /SD /Bluetooth mode,  short press : REPEAT  , ( ALL -ONE -FOLDER -NORMAL )



STOP :  Under USB /SD  mode : short press :STOP





3, Power supply DC5V /DC12V

 4, Remote Control--- Keys function



Power :ON/OFF  (standby)
Mode : Same function with Long press Play/Pause button on pannel for switch the working Mode
PREV: For Previous song in USB/TF state
NEXT: For Next song in USB/TF state
VOL+ : Volume up
VOL-: Volume down
RPT: For switching one song repeat or all song repeat in USB/TF state, default is all song repeat .
U/TF: Switch USB/TF /FM scan.
MUTE: First press mute , press again will release from mute.
EQ : NORMAL/JAZZ/ROCK/POP/CLASSIC/COUN
PLAY/PAUSE : For play and pause in USB/TF state.
Button 0-9 : Select song in USB/TF state, if the song number over 9 , just input the numbers in series .


5,Panel  dimension : 110*49 mm

Speaker amplifier usb decoder recorder bluetooth mp3 module circuit boardphoto




 JK1530 Speaker amplifier usb decoder recorder bluetooth mp3 module circuit board
