MLCC Radial Leaded Multilayer (MONO) Ceramic Capacitor

FOB Price:	0.01 - 0.10 USD/Piece

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Quick Details

Type	CC41 CC4 CC42 (NPO)	CT41 CT4 CT42 (X7R)	CT41 CT4 CT42 (Y5V Z5U)
Capacitance Range	0.1pF - 0.22uF	100pF - 2.2 uF	1000pF - 14.7uF
Temperature Coefficient	0±30PPm/℃(-55℃ - +125℃)	±15℃(-55℃ - +125℃)	+30% - 80%(-25℃ - +85℃)
Insulation Resistance	C≤10nF IR>10000MOhm C>10nF C.R>100S	C≤25nF IR>4000MOhm C>25nF C.R>100S
Dielectric Test Voltage	2.5×WVDC
Dissipation Factor	0.15%max ±0.2 (20℃, 1MHz, 1VDC, 75%)	2.5%max ±0.2 (20℃, 1KHz, 1VDC, 75%)	3.5%max ±0.2 (20℃, 1KHz, 0.3VDC, 75%)
Voltage Ratings	25, 50, 63, 100VDC		25, 50, 63VDC
Capacitance Tolerance	B=±0.1pF, C=±0.25pF, D=±0.5pF, F=±1%, G=±2%, J=±5%, K=±10%, M=±20% (B.C.D for C<10pF)	K=±10%, M=±20%, S=+50% - 20%	M=±20%, S=+50% - 20%, Z=+80% - 20%, P=+100% - 0%
Life Test (1000 hours)	200% rated voltage at +125℃		150% rated voltage at +85℃
Notes	Customization for special specification and requirement is available. Request Datasheet: Please contact with directly.
