Single Fiber 1000M Gigabit Ethernet WDM Fiber Media Converter

FOB Price: 10.00 - 100.00 USD/Bag
Supply Ability: 10,000 Bag(s) per Month
Payment Terms: T/T
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China
Packaging Details: box

Quick Details

  • Brand Name: htfuture
  • Wavelength: 0.12
  • Data Rate: 10g
  • warranty: 3years
  • Connector: lc
  • Model Number: HTF-1110S101A80
  • colour: black
  • power: 220
  • Temperature: 80

Specifications

HTFuture Single Fiber Gigabit Ethernet WDM Fiber Media Converter (Electric to Optic Converter) is designed to convert data signal between 10/100/1000BaseT(X) to 1000Base SX/LX/ZX Gigabit Ethernet. The media converter is connected between Single Fiber cable and Twisted cable segments with network operating smoothly. The Ethernet transmission distance of 100 meters from copper extended to 550m (multimode fiber) or 100 km (single mode fiber).Using sophisticated switching Core, support hot-swappable, with flexible, efficient, reliable, etc. It′s Widely used in Telecommunications, Broadcasting, Broadband networks, Million High-definition video surveillance ect. Where require high-performance, high-reliability Network environment.Features:

L the Fiber Optic is 1000M full duplex and the Electric interface is 10/100/1000M automatically configure in TP port.

L the Max transmission distance: Single mode 80KM.

L Using sophisticated switching core and Large capacity of cache.

L Supports LFP(Link Fault Pass-through),Broadcast storm protection, Balanced Traffic, Isolate conflicts and detection error.

L Compliant with IEEE802.3z, 1000Base-SX/LX/ZX, IEEE802.3ab1000Base-T Standards

L High-quality laser device has good optical Properties, electrical properties and temperature stability.

L Science Circuit layout, anti-interference Ability, can effectively prevent lightning.

L Working status indicator is complete, which Can easily manage devices.

L External professional switching power Supply, security and stability. Power consumption is less than 4W.

L Built-in lightning protection circuit, Greatly reduce the damage caused by lightning induction.



Specifications

Fiber Optical Interface

10/100/1000M Ethernet Interface

Optical Port:

SC/FC/ST, 100Mbps (single port)

Ethernet Port:

1-port RJ45

Fiber Optic (Single mode):

9/125, 10/125um

Rate:

10/100/1000M adaptive, full/half duplex Automatically

Standards:

Compliant with IEEE802.3z/AB 1000Base-T, 1000Base-SX/LX

Working Environment

Power supply:

AC100~260V/DC5V

Power consumption:

<5W

Operating Temperature:

0~50

Storage Temperature:

-40~+70

Relative Humidity:

5%~95%

Dimensions(mm):

93(L) x 70(W) x 26(H) mm



Order Information

Part Number

Description

HTF-1110S101A25

10/100/1000M Ethernet, Single-mode Fiber Media Converter, 1310nm, SC Simplex Port, 25KM, with external power (The Products must be used by pairs)

HTF-1110S101A40

10/100/1000M Ethernet, Single-mode Fiber Media Converter, 1310nm, SC Simplex Port, 40KM, with external power (The Products must be used by pairs)

HTF-1110S101A60

10/100/1000M Ethernet, Single-mode Fiber Media Converter, 1310nm, SC Simplex Port, 60KM, with external power (The Products must be used by pairs)

HTF-1110S101A80

10/100/1000M Ethernet, Single-mode Fiber Media Converter, 1310nm, SC Simplex Port, 80KM, with external power (The Products must be used by pairs)
