China Manufacturer with main products: Miniature Circuit Breaker(MCB), Residual Current Circuit Breaker(RCCB), Molded Case Circuit Breaker(MCCB), RCCB, MCB, MCCB, Circuit Breaker,... |
ID Electrical Circuit Protection
| Supply Ability: | 200,000 Piece(s) per Month |
|---|---|
| Shipping: | 15- 30 days to China port |
| Payment Terms: | L/C, T/T, Western Union |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | Export carton |
Quick Details
- Poles Number: 2P/4P
- Type: Residual Current
- Brand Name: CNHUNG
- Rated voltage: 230 / 400V
- Certificate: CCC,CE
- Model Number: ID
- Type: Electric/Megnatic
Specifications
Main Specification
Poles:2P/4P
Rated Current(A):25,40, 63,100
Rated Voltage(V):AC230 / 400V
Frequency:50 / 60Hz
Rated residual
Action current(mA):30, 100, 300
Number of poles |
2P, 4P |
Rated Current(in) |
25,40, 63,100A |
Rated residual operating current( In) |
30, 100, 300mA |
Rated residual non-operation Current( Ino) |
0.5In |
Rated Voltage(Un) |
AC 2P: 230 / 240V 4P: 400 / 415V |
Residual operating current scope |
0.5In~In |
Residual current off-time |
00.3s |
Type |
A, AC |
Ultimate short-circuit breaking capacity (Inc) |
3000A |
Endurance |
4000 |
Terminal protection |
IP20 |
ID series Residual current Circuit breaker (without over-current protection) is suitable for the line of AC 50/60Hz,voltage 240V(2pole)/415V(4pole),rated current up to 63A.When there Is human electricity shock or if the leakage current of the line exceeds the Prescribed value, RCCB will cut off the power rapidly to protect human safety and prevent the accident due to the current leakage.
It can be used as infrequent changeover of the Line in normal situation. RCCB is applicable to industrial area, commercial Area, tall building and civil house.
It complies with standard IEC/EN61008.1 and
GB16916.1
about
US
1. We Forever Champion Group specialize in the R&D, manufacture and sale of low voltage electric applicants, such as RCCB,MCB, MCCB and Accessories and so on.
2.We have seven years of manufacture and exporting experience.
3.We Have had a good reputation in Iran, Pakistan, India, Bangladesh, south American Market and so on.
4. Our brand is CNHUNG.We can also provide OEM and ODM service.
5. Already get the certificate of ISO9001,CE.
