High Low Temperature Pressure Test Chamber, Laboratory High Temperature Low Air Pressure Climatic Test Chamber Supplier

FOB Price: 10,000.00 - 90,000.00 USD/Set
Supply Ability: 30 Set(s) per Year
Shipping: 30 working days, shenzhen, Guangzhou port
Payment Terms: L/C, T/T, Western Union
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China
Packaging Details: High low temperature pressure test chamber will be packaged well by wooden box

Quick Details

  • Brand Name: simplewell
  • color: grey
  • Theory: Testing equipment
  • Resolution: High
  • Size: 324L
  • Model Number: KU

Specifications

High low temperature pressure test chamber

High- low temperature low pressure test chamber, test equipment for research institution, environmental test chamber

High low temperature pressure test chamberLaboratory high temperature low air pressure climatic test chamber supplier

Application

The high low temperature low pressure test chamber is often used for military uses. Sometimes, the low pressure chamber simulates the high mountain environment for testing vehicles, computers, electronic components and packaging materials that need air transport.


Product
purpose

Apart from the military applications, the high and low temperature/ low air pressure test tank (low air pressure test tank)

is used for car test under mountain environment and testing the airborne computer, electronic element and package


Reference
Standards

GB10590-89 Specifications for Low Temperature/Low Air Pressure Testing

GB15091-89 Specifications for High Temperature/Low Air Pressure

GB11159-89 Specifications for Low Air Pressure Testing Chambers

GB/T2423.25-1992 Low Temperature/Low Air Pressure Comprehensive Test

GB/T2423.26-1992 High Temperature/Low Air Pressure Comprehensive

GJB150.2-86 Low Temperature/Low Air Pressure (Height) Test


Technical parameters of high low temperature low pressure test chamber

Model

KU-504-40

KU-1000-40

KU-504-70

KU-1000-70

Volume (L)

504L

1000L

504L

1000L

Inner size   (DxWxH)mm

800x700x900

1000x1000x1000

800x700x900

1000x1000x1000

Temperature range

-40°C+150°C

-70°C+150°C

Temperature fluctuation

±1.5°C

Temperature deviation

100°C, ±3.0°C(Normal pressure no-load),<100°C, ±2.0°C(Normal pressure no-load)

Warm-up   time

(0.7°C ~1.0°C /Min )(Total average)

Pressure range

Normal pressure ~1 kpa

Pressure deviation

40kpa,±2kpa;   4kpa~40kpa, ±0.5kpa;    4kpa, ±0.1kpa

Rate of pressure reduction

Normal pressure~1 kpa (Under the state of normal temperature)

Pressure recovery rate

10kpa/Min (adjustable)

Material

Shell

Anti   -rust cold rolled sheet steel (surface spraying plastics)

Inner shell

Stainless steel plate SUS304

Pressure   bearing - material

Anti-rust high-quality thick steel   plate (surface spraying plastics)

Thermalinsulation

High-quality glass cotton

Regulatr

Refrigerator

Semi-hermetic compressor

Cooling mode

Air cooling or Water cooling

Vacuum   pumping mode

Mechanical   rotary-vane vacuum pump

Heater

High-quality nickel-chromium alloy fin heater

Fan

Magnetic drive motor

Door observation window

Hollow glass of circular observation window   heating film

Temperature   sensor

Thermal   resistance and thermocouple

Controller

Touch screen controller

Standard   configuration

Observation window, testing hole (1   at left side) , plate, plate frame(2 sets)

Safety device

Over-temperature protection, oil   lacking, over-voltage, overload protection of compressor, fan overload   protection, power phase loss protection, leakage protection, water lacking   protection (water cooling) and vacuum pump fault alarm

Selection

Recorder   added plate and special sample rack

Remarks: ※Select the low air pressure and low temperature ontrolquipment(our ompany has technical ability to meet the ontrolrequirement of temperature and umidityunder low air temperature)


Note: our company has the technological capacity to simultaneously satisfy the temperature requirements and humidity requirement under low pressure.

High low temperature pressure test chamberLaboratory high temperature low air pressure climatic test chamber supplier

Optional configurations

1.      Rotary dehumidifier/ polymeric membrane, with a lowest temperature/humidity content of 5℃/5%RH.

2.      Built-in tempered glass door, easy to move.

3.      Water purification system, with automatic replenishment function.

4.      Recorder, save and print testing data.

5.      Ultrasonic humidifier/high-pressure spray humidifier, providing continuous high humidity under extreme temperature.

6.      Dry air blow system, anti-condensation

7.      Remote monitoring function, cellphone and computer supportive.

 High low temperature pressure test chamberLaboratory high temperature low air pressure climatic test chamber supplier

Cooling equipment

High low temperature pressure test chamberLaboratory high temperature low air pressure climatic test chamber supplier



Cases

Through more than 20 years of hard work, we have established friendly relationship with customers both at home and abroad. Some of them are well-know companies and organizations, like SGS, SONY, TUV AND FORD, etc.
