Upsetting Forged Machine
| FOB Price: | 5,500.00 - 7,500.00 USD/Set |
|---|---|
| Shipping: | Suit for sea transportation |
| Payment Terms: | L/C, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hebei in China |
| Packaging Details: | wooden package |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Brand Name: YD
- COLOR: RED
- name: upsetting forged machine
- Weight: 950
Specifications
Technical parameter
1. Range of application: 16mm-32mm
2.Voltage:380V
3. Maximum working pressure: <=25MPA
4. Total power of electric (al) motor: 7.5KW
5. Out Dimension: 1550*570*1100mm
6.Weight:950KG
Product description
the rebar cold forging upsetting machine is mainly used for construction of ribbed steel bar rolling straight thread head, it is an important equipment of steel bar connection.
the rebar cold forging upsetting machine use the cold heading principle to make the steel end for plastic deformation, diameter increased 4 ~ 6mm, and then processing thread.
Feature
1.It can process steel bars with diameter ranging from 16-32mm.
2.It greatly improves the tensile strength of the joint
3.High efficiency, can produce 300-500 pieces per machine.
4.Environmental protection, safety, economy,low cost.
PROCESSING STEP
the ends of the bars to be joined are cut square and enlarged by cold forging to increase their core diameter and so ensure that the joint is stronger than the bar. The couplers are usually supplied attached to the reinforcing bar.
1. First use the upsetting machine to thicken the end of the rebar end,
2. Then use the steel bar threading (cut) machine to make thread on the end of rebar's.
3. Connect the two rebar end with the upsetting rebar couplers.
