Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20843

Supply Ability: 1,000,000 Piece(s) per Month
Shipping: 14 days for ready goods, Shenzhen, Hongkong, Guangzhou
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Safebuy
  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China
Packaging Details: 200 pcs per carton box

Quick Details

  • Application: Handset
  • Jacket: Thermoplastic Elastomer
  • Insulation Material: Thermoplastic Elastomer
  • Conductor Material: Copper
  • Brand Name: WCH Cable
  • Number of Conductors: 2 Cores
  • Model Number: UL20842
  • Feature: Waterproof
  • Conductor: High Purity Copper Wire
  • Jacket: LSZH Compliant
  • Manufacturer: WCH Cable Industrial Co., Ltd.

Specifications

WCH Cable () is engaged in field of cable and wire manufacturing. WCH Cable is the cable manufacturer since the year 1997. WCH Cable makes many cables and wires, including Hook-up wire, Automotive wire, Flat ribbon cable, Power cable, Communication cable, Curly cord (Polyurethane Spiral cable), etc.



for many years experience, WCH Cable has created himself the great position of advantage in the market. As one of the leading manufacturers in China, WCH Cable are focused on cables and wires approved by Underwriter Laboratories (UL). up to now, WCH Cable owns over 600 UL Cable Approval style numbers. Apart from this, WCH Cable also wins the approval of CSA, CUL, VDE, CCC as well.



WCH Cable guarantees the good quality. WCH Cable production lines manufacture cables and wires with oxygen-free pure copper conductors only, of which the purity is up to 99.997%. Higher copper conductor purity makes the cables and wires with perfect electrical conductivity, wonderful processing performance, good corrosion resistance and so on.



WCH Cable integrates business worldwidely with providing the competitive advantage of safe, cost effective, and innovative products. WCH Cable products are applied widely for all major industries including government, military, automotive, aerospace, telecommunication and electronic appliances.



to Meet the market with growing demand, WCH Cable has expanded its product range, covering varieties of different insulated materials and jacketed materials, such as TPU, PUR, TPE, TPV, FEP, FR-PE, XL-PE, XL-PVC, PVC, mPPE, mPPE-PE, Rubber, Silicone Rubber, etc.



WCH Cable continuously make significant technology progress, keep pace with industry standards and acquire the most advanced manufacturing equipment and tooling. In addition, our highly skilled manufacturing and engineering staff are fully committed to a high quality program and ensures the highest quality workmanship available.


with many years experience of cable and wire design and manufacturing, WCH Cable makes every product renowned for its elegant appearance and flawless finish. WCH Cable Will Continually promote the strategy and keep progressing.



WCH Cable manufacturing lines implement Quality management approval ISO9001, Hazardous substance management QC080000. All Cables and Wires provided by WCH Cable are hazardous substance free. WCH Cable is sincerely looking forward to being your best business partner.Waterproof Handset Retractile Curly Cord UL20842 UL20843 UL20843

Waterproof Handset Retractile Curly Cord UL20842 UL20843 UL20843



Waterproof Handset Retractile Curly Cord UL20842 UL20843 UL20843

Spiral Cable
Construction
Spiral Length (unexpanded) (mm) 80
Straight Ends (mm/mm) 610/350
Extension Ratio 1:3.8
Spiral Outer (mm) 17.5
Tail Direction 180 Degree
End Treatment Optional Cut Flat, Stripped/Tinned
Electrical
Capability
Working Voltage (V) 300
Temperature Range (C) 80
Test Voltage (V) 2000/3000
Nominal Voltage (V) 300
Conductor Resistance (/KM at 20C) 14.60
Insulation Resistance (M/KM at 20C) 100
Standard & Use UL Style Number Optional Per UL20842, UL20843, UL20843
CUL Standard II A
Flammability FT1, VW-1
Raw Cable
Construction
Conductor Size (AWG) 16
Insulation Material TPE (RoHS)
Insulation Diameter (mm) 2.20
Conductor Quantity 2 Cores
Assembly Twisted
Overall Diameter (mm) 5.30
Jacket Material TPE (RoHS)
Surface Effect Matt Black
