Roho Communication Technology Co., Ltd.
China Manufacturer with main products: RF Coaxial Connector, RF Cable Assembly, SMA Connector, IPEX Connector, RF Coaxial Antenna |
High Quality RF Coaxial Connectors & Cable Assemblies
| Supply Ability: | 100,000 Piece(s) per Quarter |
|---|---|
| Shipping: | as your required |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, Other, paypal |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | 1.Foam + Carton 2.Blister + Carton 3.Vacuumize + Blister + Carton 4.Vacuumize + Foam + Carton |
Quick Details
- Gender: Female
- Application: Audio & Video
- Type: Adapter
- Brand Name: roho
- Color: gold and Ni.
Specifications
| ELECTRICAL DATA | |
| Impedance | 50 |
| Frequency Range | Flexible cables DC 11GHz, semi-rigd cables DC18GHz |
| Withstand Voltage | 2500V,50Hz |
| Working Voltage | 1000V,50Hz (sea level) |
| Insulation Resistance | 5000m |
| Contact Resistance | Inner conductor:1.0m |
| Outer conductor:0.2m | |
| RF leakage(2-3GHZ) | Flexible:90dB |
| 3rd order intermodulation | 140dBc |
| MECHANICAL DATA | |
| Coupling nut torque | Recommended: 68Ncm--123Ncm / 6.0 in. Lbs--10 in.Lbs |
| Proof torque: 170 Ncm / 15.0 in.Lbs | |
| Proof torque | 170Ncm / 15.0 in.Lbs |
| Durability (matings) | 500 |
| ENVIRONMENTAL DATA | |
| Temperature range | -65C to +165C |
| MATERIAL DATA | |
| Bodies | Brass--Ternary alloy plating |
| Pin contacts | Brass--Au/Ag plating |
| Socket contacts | Copper beryllium alloy--Au plating |
| Crimp ferrules | Brass-- ternary alloy plating |
| Insulator | PTFE |
| Gaskets | Silicone rubber |
