Micro Motion CNG050 Coriolis Flow Meter

Shipping:	FOB Shanghai
Payment Terms:	T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Packaging Details:	Carton or Customized by customers' requirements

Quick Details

Brand Name: Micro Motion
Accuracy: 0.50%
Power Supply: 24V
output: 4-20 mA
Medium: natural gas
Model Number: CNG050
Line Size: DN15 -DN20
Pressure Range: 5000 psig (345 barg)
Temperature Range: 40~ 125

Specifications

Micro Motion CNG050 Coriolis Flow Meter

Micro Motion CNG050 Coriolis Flow Meter

Introduction

Single-meter CNG flow meters meet the challenges of measuring compressed natural gas for custody transfer in light- and heavy-duty vehicle dispensers while reducing fill time with higher flow rate capability.

Specifications

Gas Accuracy / Repeatability

0.50% of batch ( 0.25% of rate)

Line Size

1/2" 3/4" (DN15 DN20)

Pressure Range

5000 psig (345 barg)

Temperature Range

-40 to 257 F ( - 40 to 125 C)

Electronics (soft)

Expansive I/O options including mA, Frequency, Discrete Input/Output, HART, Modbus, Ethernet/IP, FOUNDATION Fieldbus

Turndown

10:01

Features

Satisfy needs for light- and heavy-duty vehicle dispensers with a purpose-built, single-meter solution

Use with most fluids with available 316L stainless steel construction

Choose from a wide range of transmitter options, including direct-connect, to accommodate dispenser design requirements

Broad range of meter approvals and certifications, including; CSA (Class 1 Div 1 groups C and D, Class 1 Div 2 groups A, B, C and D, Class II Div 1 groups E, F and G), ATEX, NEPSI, IECEx, Ingress Protection 66/67, and NAMUR

Save time with a compact design with no moving parts, requiring no special mounting or flow conditioning

Rely on custody-transfer-approved certification

Common models

CNG050S239NQBMAZZZ

CNG050S239NABMAZZZ

CNG050S239NCBMAZZZ

CNG050S239NWBMAZZZ

CNG050S239NDBMAZZZ

CNG050S290NQBMAZZZ

CNG050S290NABMAZZZ

CNG050S290NCBMAZZZ

CNG050S290NWBMAZZZ
