Home >Products Catalog > 4 Port 1.3,1.4,2.0 HDMI Switcher Support 4K/60Hz & 3D for HDTV

4 Port 1.3,1.4,2.0 HDMI Switcher Support 4K/60Hz & 3D for HDTV

Supply Ability:	3,000 Piece(s) per Week
Shipping:	air transportation or sea delivery
Payment Terms:	T/T, Western Union

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	default box

Quick Details

Brand Name: Olive
Weight: 238g
Color: silver
size: 178x67x23 (mm)
Transmission Distance: 15m
Model Number: HDSW4-V2.0
HDMI Version: HDMI 2.0a
HDMI Resolution: up to 4K/60Hz
Max Working Current: 350mA
power supply: DC5V/1A

Specifications

Functions

-Support HDMI 2.0a
-Support 3D
-Support highest video resolution 4K/60Hz
-Support 6Gbps data rate for tmds clock up to 600MHz
-Support 24/30/36 bit deep color
-Support standard AWG26 cable, input up to 8 metres,output up to 8 metres (4K/30Hz or lower)
-Support standard HDMI 2.0 cable, input up to 3 metres,output up to 5 metres(4K/60Hz)
-Support single and high definition display for multiple sources, such as DVD Players
and Satellite Receivers, HD players, PS4, Set top Boxes.
-Need DC5V/1A power supply

4 Port 131420 HDMI switcher Support 4K60Hz and 3D for HDTV

4 Port 131420 HDMI switcher Support 4K60Hz and 3D for HDTV

Operating and Connecting:
1: Connect four cables from HDMI source device into HDMI switch input.
2: Connect one cable from HDMI source device into HDMI switch output.
3: Connect 5V/1A power adapter to the HDMI switch.

Specification

HDMI Version:	HDMI 2.0a
HDMI Resolution:	4K/60Hz
Support Video Format:	3D
Support Audio Format:	DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
Max Bandwidth:	600MHz
Max Baud Rate:	6Gbps
Input Cable Distance:	8m AWG26 HDMI standard cable(4K/30HZ); 3m 2.0 HDMI standard cable(4K/60HZ)
Output Cable Distance:	8m AWG26 HDMI standard cable(4K/30HZ); 5m 2.0 HDMI standard cable(4K/60HZ)
Max Working Current:	350mA
Power Adapter Format:	AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature Range:	(-10 to +55)
Dimension (L x W x H):	178x67x23 (mm)
Weight:	238g
