Home >Products Catalog > Hot Air Seam Sealing Tape Machine for Ski Suit, Outdoor Jacket

Hot Air Seam Sealing Tape Machine for Ski Suit, Outdoor Jacket

Supply Ability:	50 Set(s) per Month
Shipping:	BY SEA OR AIR
Payment Terms:	L/C, T/T, Western Union, MoneyGram

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	strong wooden case

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Usage: Hot air seam sealing tape machine
Weight: 160KG
Voltage: AC220/380/400/415/440V 3PHASE
Brand Name: Jingyi
Dimensions: 1300*550*1650MM
Welding Area: Customize
Frequency: 0
Power: 1800W
Model Number: JY-1800

Specifications

Machine Description

Introduction of Hot Air Welding Machine:
Hot air welding machine has unique advantage in inflatable products made of membranes structure, which is total different with high frequency welding and hot melt welding technology, the hot air is blew between the sealing surface, under necessary suitable pressure to get perfect welding effect, PVC, TUP material are all available, which are made to water polo, water drum, grass ball, inflatable swimming pool, large inflatable tents, inflatable boats, rubber boats and fishing boats and etc.

Welding material:
1.Vinyl (PVC) laminated fabric
2.Vinyl coated fabrics
3.Vinyl Films
4.Polyurethane film
5.Polypropylene coated fabric
6.Polyethylene (PE)
7.Thermoplastic rubber (TPR) film
8.Thermoplastic rubber fabrics
9.Nonwoven polyester
10.Various fusing tapes
11.Weldable webbings
12.Rigid extruded products

Features of Hot Air Welding Machine:
1. TSI operating procedures,stepper motor,digital display,setting parameters can be adjusted by your need.
2. Automatic temperature control,steady operation, temperature accuracy 2C,temperature limit design to protect the heating fuse.
3. Synchrodrive of upper and lower rollers,automatic adjust the virtual space and micro-recede to reduce the mistake.
4. Double feet control,easy operation,not easy weary,suitable for long time operation.
5. the independent design of control procedures of heating tube,blower delay function to protect the heating tube.
6. 24-hour production, improve production efficiency.
7. Automatic cut, tape-feed and seal to reduce material loss.
8. Controlled by stepper motor,precise in tape feeding.
Hot air seam sealing tape machine For ski suitoutdoor jacket

Specification

Model	JY-1800	Adhesive tape width	14mm22mm (Can be sustomized)
Voltage	AC220V 50HZ	Width of roller Standard	25mm (Can be customized)
Rated power	2500W	Upper roller lift	18mm25mm
Temp control	up to 700	Size:(LWH)	1500x700x1620mm
Speed	122m/min	Gross weight	200KG
Air compression	0.350.5Mpa
Sealing skip prevention	Adjustable inward and outward movement of heating tube,rooler start and stop prevent sealing skip.

Application

Hot air welding machine is suitable to produce all kinds of waterproof product which is made from coated PU,PVC,TPU, PE, PVA, such as large tent, inflatable boat and children toys, car covering,etc.
Hot air seam sealing tape machine For ski suitoutdoor jacket
