XCMG Road Machine Paver Rp Series Paver 602

Supply Ability: 1,000 Unit(s) per Month
Shipping: shipment
Payment Terms: T/T
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Guangdong in China

Quick Details

  • After-sales Service Provided: Engineers available to service machinery overseas
  • Certification: ce
  • Weight: 16t
  • Brand Name: xcmg
  • Condition: New
  • Warranty: 1 year
  • Dimension(L*W*H): 6230*2500*3855
  • Model Number: rp602
  • Paving Width: 6m
  • Max. Paving Thickness: 380mm
  • Power(W): 118
  • Production Capacity: 13

Specifications

XCMG road machine paver rp series paver 602
Power transmission technique: high-efficient and powerful
Deutz water-cooled diesel engine with strong power adopts high-pressure pump structure, featuring good diesel oil atomization and economical efficiency, long service life, and extensive application range.
the hydraulic pump and motor of Linde and Rexroth adopted have long service life, featuring big driving torque, low load rate, and reliable performance.
Control technique: stable and precise
Material feeding adopts synchronous drive, and the rotate speed is controlled by full proportional control. the material level adopts ultrasonic control technique which can control the height of the material level stably. the manual gearshift adopts infinitely variable control.
Speed control of material distribution: the manual gearshift and automatic gearshift can be switched freely.
Electronic automatic leveling ensures higher evenness. Many sensing modes and high automaticity can meet the construction requirements of high-grade roads.
Digital micro-computer control can pre-select the speed. Adopt the constant speed automatic control technique, ensuring the paving speed not impacted by the load. during moving, the paving speed and travel speed can be switched freely.
Material feeding and distribution technique: reliable and durable
Strong material distribution capacity: It adopts 360mm coarse pitch, 420 large diameter blade, and 28BH reinforced drive chain, the drive capacity is higher 25% than the similar products.
the material distribution box and chain adopt high-intensity design, which can supply strong transmission power. the maximum power transmission capacity of the material distribution shaft is 5000Nm, which can achieve full buried distribution, greatly reducing the segregation.
There are two reverse blades in the middle of the material distribution box, reducing the middle segregation zone.
Screed technique: mature and reliable
Mature and reliable hydraulic telescopic screed: the reasonable dimension match of the telescopic cylinder and sleeve features the excellent glide accuracy and good reliability, ensuring the paving quality.
3-point suspension mechanism ensures stable stretch and retraction
the infinitely adjustable vibration frequency (575 screed) meets the requirements of different working conditions.
Adopt the electrical heating, featuring safety, environment protection, and convenience.

Performance advantages
Excellent configuration
the key parts such as diesel engine, hydraulic pump, hydraulic motor, hydraulic valve, travel reducer, micro-computer controller, bearings, hydraulic pipe joints, hydraulic tube and hose, and filters are imported from European countries, ensuring the durability and reliability of the machine.
Simple maintenance
Central controlled operation features simplicity and reliability. All the operating components are installed on the instrument box, the instrument box is moveable.
There are numbers on all the electrical circuits, which is convenient to check and maintain.
the side cover and engine hood is easy to open, and the components that need to be maintain usually are easy to access to.
the travel drive device adopts outboard cover, which is convenient to maintain.
Excellent performance
the maintenance-free crawler travel device composed of track rollers and rubber track shoes is durable, and doesn't damage the roads.
the imported automatic centralized lubricating system prolongs the service life of the bearings in high-temperature positions, greatly reducing the amount of maintenance and improving the working efficiency.

Item Unit RP602
Basic paving width m 2.5
Max. Paving width m 6
Max. Paving thickness mm 380
Paving speed M/min 014
Travel speed km/h 03.0
Theoretical productivity t/h 400
Hopper capacity t 13
Gradeability % 20
Pavement evenness Mm/3m 3
Cross slope error % 0.03
Crown adjustment range % 03
Diesel engine model BF4M1013C
Diesel engine power kw 118
Diesel engine speed R/min 2300
Diesel oil tank capacity L 230
Overall weight t 15.821.5
Dimension mm 623025003855
Vibration frequency Hz /
Screed heating mode Electrical heating
Material level control mode Automatic Control by Ultrasonic Sensor
Automatic Leveling Control Simulation control

Item Unit
Screed model 475(RP602)
Type Vibration, electrical heating
Stretch mode Hydraulic stretch
Width range 2.5-6.0m
Vibrating tamper rotate speed 0-1500r/min
Vibration frequency 4mm
