YB-1650E Automatic Flute Laminating Machine
| Supply Ability: | 15 Set(s) per Month |
|---|---|
| Shipping: | FOB Ningbo or Shanghai |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Quick Details
- Type: Laminating Machine
- Automatic Grade: Automatic
- Condition: New
- After-sales Service Provided: Engineers available to service machinery overseas
- Certification: CE
- Weight: 5500KG
- Dimension(L*W*H): 11500*2400*2400
- Model Number: YB-1650E
- Brand Name: Youbond
- Power: 22kw
- Voltage: 380v/50hz
- Driven Type: Manual
- Max sheet size: 1650*1450
- Min sheet size: 500*500
Specifications
YB-1300/1450/1650E Automatic flute laminating machine
Brief Introduction
this machine could be used for the lamination of color top sheets and corrugated paper. Top paper is sent in a scale continous way, the way of front gauge positioning insures that the bottom paper would never exceed. this automatic laminator is easy to operate and matian.
Specification
Model |
YB-1300E |
YB-1450E |
YB-1650E |
Max Sheet |
1300*1250mm |
1450*1250mm |
1650X1450mm |
Min Sheet |
400X400mm |
400X400mm |
400X400mm |
Top Paper Thickness |
150GSM-600GSM |
150GSM-600GSM |
150GSM-600GSM |
Max Speed |
7000sheets/hour |
7000sheets/hour |
7000sheets/hour |
Fitting Precision |
1.5mm |
1.5mm |
1.5mm |
Measurement |
11.5*2*2.4M |
11.5*2.2*2.4M |
11.5*2.2*2.4M |
Machine Weight |
5000kg |
5500kg |
6000kg |
Machine Power |
10KW/380V |
11KW/380V |
12KW/380V |
Bottom Paper Thickness |
A,B,C,E,F,AB,BB,BC,EE/ Corrugated paper/ Industry coardboard | ||
