Watertight Cable Gland PG Thread

FOB Reference Price: $ 1
Wholesale: ?Y1000 Piece(s)
Supply Ability: 100,000 Piece(s) per Month
Shipping: By sea,By air,and by express
Payment Terms: L/C, T/T, Western Union
Update Time: 2019/6/25
  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Packaging Details: Standard export packing

Quick Details

  • Material: Brass
  • Size: PG7-PG63
  • Protection Level: IP68
  • Brand Name: Sanhui
  • Color: Metal color
  • Model Number: SH-
  • Materials: Brass/Brass,nickel planted/Stainless steel
  • Claw: PA66
  • Seal: NBR
  • Working temperature: -40 to 100
  • Certificate: CE,IP68
  • Thread: M,PG,G,NPT
  • Customization: Accept
  • Install: Thread tighten/Lock nut tighten
  • OEM/ODM: OK

Specifications

Product Features

Thread length:Standard thread type is used for the equipment which has inner thread or for the thin board.Long thread type is used for the thin board.Long thread type is used for the thick board.
Function:Extremely easy installation,simply insert cable through the assembled gland and tighten gland lock nut until cable is secured.these cable glands are designed to withstand water,dust,salt,acid-base,alcohol,oil and common solvent.
Usage:Waterproof brass cable gland is the product of form a complete set of the cable,connector cable can be locked,the other end can access devices on the box body,also can choose thread access according to th import and export for internal thread electric devices.

watertight cable gland PG thread
Code Item AG Cable range (mm) Thread O.D. (mm) Thread length (mm)GL Spanner size (mm)
SH-PG7 PG7 6.5-3 12.5 7 14
SH-PG9 PG9 8-4 15.2 8 17
SH-PG11 PG11 10-5 18.6 8 20
SH-PG13.5 PG13.5 12-6 20.4 8 22
SH-PG16 PG16 14-10 22.5 9 24
SH-PG19 PG19 14-10 25 9 24/27
SH-PG21 PG21 18-13 28.3 9 30
SH-PG25 PG25 22-15 32 10 35
SH-PG29 PG29 25-18 37 11 40
SH-PG36 PG36 33-25 47 12 50
SH-PG42 PG42 38-32 54 13 57
SH-PG48 PG48 44-37 59.3 14 65
SH-PG63 PG63 52-42 72 15 77

Our Factory
watertight cable gland PG thread
