Horizontal Multi-Functional Film Continuous Rice Bag Sealing Machine for Plastic Cloth Packaging Carrier Bag SafeBuy Supplier Member

FOB Reference Price: $ 4500
Wholesale: ?Y1 Set(s)
Supply Ability: 60 Set(s) per Month
Shipping: sea transportation
Payment Terms: L/C, T/T, Western Union, MoneyGram
Export Markets: North America, South America, Africa, Mid East, Eastern Asia
Place of Origin: Zhejiang in China
Packaging Details: Fumigated wooden box

Quick Details

  • After-sales Service Provided: Engineers available to service machinery overseas
  • Warranty: 1 year
  • Certification: CE
  • Brand Name: Allfine Group
  • Condition: New
  • Weight: 500KGS
  • Dimension(L*W*H): 3.5x1.72x1.63m
  • Power(W): 2.7kw
  • Voltage: 220V, 2Phase, 50Hz
  • Model Number: LC-1400FDS
  • Material: Plastic
  • Bag Type: Patch Bag
  • Machine Type: Sealing Machine
  • Single-Sided Thickness Of Film: 0.008-0.15mm
  • Max Bag Making Width: 100-700mm
  • Name: Horizontal multi-functional Film continuous rice bag sealing machine for Plastic cloth packaging Carrier Bag

Specifications

Horizontal multi-functional for Plastic cloth packaging Carrier Bag

HD video link about LC-1400FDS film folding and side sealing machine


HD video link about LC-PE tube film side gusseting machine edge Inserting machine


================================================================
HD video link about LC-600 Plastic T-shirt bag making machine
Https://youtu.Be/ZpTga-G8xzI
================================================================
HD Video link about LC-45 mini type film blowing machine
Https://youtu.Be/d1BY1mQprn0

HD Video link about LC-1500 PE film blowing machine extruder (1500mm width, export to Bangladesh)
Https://youtu.Be/ahjr26sz_aI

Video link about PE film blowing machine (800mm width)
Https://youtu.Be/u1fE5WYQtNw

Video link about PE film blowing machine (1500mm width)
Https://youtu.Be/UZE33UWpzSc

================================================================

Flexo printing machine (6 colors, 1000mm width, 60m/min printing speed)
Https://youtu.Be/1x1PsG66ecI

================================================================


Usage

    this film folding machine is used for folding the single-layer sheet PP OPP film and then rewinding, which is an assistant equipment of the bag sealing and cutting machine for making garment bag, sock bag, towel bag, bread bag, ornament bag, underwear bag, stationary bag, electric element bag, bamboo article and wooden products bag etc. Plastic packing bags.
* It equips with bottom-gusset device, adhesive tape inserting device, pearly-lustre film inserting device.




Optional Devices

1. Ultrasonic Sealing Device
2. EPC web guider device (film edge position control) including guider controller, guider motor, double sets of photocells, and magnetic powder tension controller.



Main specification

Model LC-1200FDS LC-1400FDS LC-1600FDS LC-2000FDS
Max unwinding width 1200mm 1400mm 1600mm 2000mm
Max rewinding width 600mm 700mm 800mm 1000mm
Max material diameter 500mm 500mm 500mm 500mm
Rewinding speed 80m/min 80m/min 80m/min


80m/min

Heating power 200w 200w 200w 200w
Ultrasonic power AC1000VA AC1000VA AC1000VA AC1000VA
Power supply AC220V/50Hz AC220V/50Hz AC220V/50Hz AC220V/50Hz
Total power 2.5kw 2.7kw 3kw 3kw
Fold shelf 1.49x1.52x1.37m 1.59x1.72x1.63m 1.7x1.92x1.78m 1.89x2.2x2.1m
Rewinder 1.88x0.82x1.2m 1.88x0.92x1.2m 1.88x1.02x1.2m 1.88x1.22x1.2m
Double folder dimension 2.32x0.82x1.2m 2.32x0.92x1.2m 2.32x1.02x1.2m 2.32x1.22x1.2m


Service:
1. Installation & Training Services
Training the buyers in seller's factory by free charge; or install / debug the machines in buyer's factory, the buyers will charge for the cost.
2. after Sales Service
One year Guarantee without man made.



Horizontal multifunctional Film continuous rice bag sealing machine for Plastic cloth packaging Carrier Bag
