Mini Lab Plastic Film Extruder Machine 11KW Heating Power Easy Operation
| Supply Ability: | 60 Set(s) per Month |
|---|---|
| Shipping: | sea transportation |
| Payment Terms: | L/C, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | film package |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Brand Name: ALLFINE
- Automatic: Yes
- Blow Moulding Type: Extrusion Blow Moulding
- Condition: New
- Warranty: 1 year
- Certification: CE
- Weight: 2.5Ton
- Dimension(L*W*H): 3000*2500*4200mm
- Power(W): 34kw
- Voltage: 380V
- Model Number: LC-40X2-700
- Application: Film
- Extrusion Output(Single):: 45kg/h
- Single-Sided Thickness Of Film:: 0.01-0.10mm
- Max Folding Width Of Film:: 600mm
- Range Of Die: 100mm
- Screw Speed: 15-100r/min
- Name:: Double Color Strip Film Blowing Machine 600mm Max Folding Width Of FilmMini Lab Plastic Film Extruder Machine 11KW Heating Power Easy Operation
Specifications
Double Color Strip Plastic Extruder Film Blowing Machine for t-shirt shopping bag
Taiwan High Speed HDPE LDPE Mini Lab Film Blowing Machine for T-shirt Vest Garbage Plastic Shopping Bag
Use:
It applies to blow various LDPE, HDPE and LLDPE plastic films, widely applying to food, fruit, clothing, textile, vest type bag and etc. Packing of civil industrial products.
Feature:
1. Model LC45-600 squeezing machine is adopted fixed die head,machine tube is adopted 38CrMoAl,having the best hardness and corrosion-resisting performance after nitrogen treatment and precision processing.
2. Model LC45-600 auxiliary machine can adjust and operate freely within the range of 500mm in accordance with the technological demand of different materials, and having package board mechanism which can make vest type bag.
3. Rolling up device with double-drawing in and do-uble cutting ope, its power is adopted moment motor, with friction plate,it can keep suitable tension, drawing in and rolling up in good order, easy to change roll.
Main technical parameters:
| Model | 45 |
| Diameter of Screw(mm) | 45 |
| Max. Width of Folded Film (mm) | 100-500 |
| Single-face Thickness of Film(mm) | 0.01-0.10 |
| Max. Extrusion(kg/h) | 35 |
| L/D | 26:1 |
| Power of Main Motor(KW) | 7.5-11 |
| Power of Traction Motor(KW) | 1.1 |
| Heating Power(KW) | 11 |
| Overall Dimension (mm) | 3800*1900*3000 |
| Weight(T) | 1.5T |
Configuration:
| Temperature meter | Omron |
| Switch | Schneider |
| Inverter | Delta |
| Relay | Omron |
| Solenoid valve | Taiwan |
| Thermocouple | RKC JAPAN |
| Voltmeter | Japan |
| Ammeter | Japan |
| Barrel and screw material | 38 chrome-molybdenum aluminum, nitrogen treated |
| Gear box | Hard tooth surface |
| Head | Rotary die head |
| Winder | Double rewinder |
| Main motor | CHINESE BRAND |
| Heating ring | Cast aluminum |
| Winder motor | Torque motor |
| Embossing roller | yes |
| Power | 3 PHASE 380V 50HZ |
2.Spare Parts
| 1 | Filter net | 3M |
| 2 | Lodestone | 1 PC |
| 3 | Blowing pipe | 2 PC |
| 4 | Thermocouple | 2 PC |
| 5 | Voltage meter | 1 PC |
| 6 | Screw heater (stainless steel) | 2 PC |
| 7 | Three through heater (stainless steel) | 1 PC |
| 8 | Test pen | 1 PC |
| 9 | Screw driver | 1 PC |
| 10 | Inner hexagon wrench | 1 PC |
| 11 | Glove | 4 PC |
| 12 | Temperature meter | 1 PC |
| 13 | Current meter | 1 PC |
| 14 | AC contactor CJX1-22A/220V | 1 PC |
| 15 | Mandril | 1 PC |
3.Optional equipments should extra cost
| 1 | CORONA TREATER | USD500.00 | CHINA BRAND |
| 2 | AUTO LOADER | USD500.00 | CHINA BRAND |
| 3 | AIR SHAFT -2PCS | USD300 | |
| 4 | with pneumatic cylinder on top tower and winder side. |
USD300 | |
| 5 | Mechanics-screen changer | USD900 (for LC-50. 55) |
HD Video link about LC-45 mini type film blowing machine
Https://youtu.Be/d1BY1mQprn0
HD Video link about LC-1500 PE film blowing machine extruder (1500mm width, export to Bangladesh)
Https://youtu.Be/ahjr26sz_aI
HD Video link about LC-50-700 film blowing machine
Https://youtu.Be/tiLDZY7ueWA
HD video link about ABA 2 layers Co-extrusion PE film blowing machine
Https://youtu.Be/OIS4b52QpuQ
