>Products Catalog > pharmaceutical machine > ZP9 Pill Press Camphor Paracetamol Tablet Making Rotary Tablet Press Machine
ZP9 Pill Press Camphor Paracetamol Tablet Making Rotary Tablet Press Machine
| Supply Ability: | 20 Set(s) per Month |
|---|---|
| Shipping: | by sea or by air |
| Payment Terms: | T/T, Western Union |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Liaoning in China |
| Packaging Details: | wooden case |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Production Capacity: 9600-13440pc/h
- Type: Rotary Tablet Press
- Brand Name: LPMIE
- Condition: New
- Certification: ISO
- Dimension(L*W*H): 600X960X1150mm
- Weight: 250kg
- Power(W): 0.75KW
- Voltage: 380V
- Max. Tablet Diameter(mm): 13mm
- Max. Tablet Thickness(mm): 6mm
- Max. Pressure(KN): 40KN
- Model Number: ZP9
- Die sets' quantity: 9sets
- Turret Speed: 32r/min
- Max. Depth of Fill: Ma15mm
- Diameter of Middle Mould: 26mm
- Height of Middle Mould: 22mm
- Diameter of Up & Down Punch Pole: 22mm
- Length of Up & Down Punch Pole: 11mm
Specifications
Description:
ZP9 Pill Press Camphor Paracetamol Tablet Making Rotary Tablet Press Machine is mainly applicable for trial production in labs and small-acale production and they are automatic equipment continuously pressing particles into round and special-shaped tables with diameters no more than 13mm.
Technical parameter:achine
| Dies | 9sets |
| Max. Pressure | 40KN |
| Max. Dia of Tablet | 13mm |
| Max. Depth of Fill | 15mm |
| Max. Thickness of Tablet | 6mm |
| Rotational Diameter | 200mm |
| Turret Speed | 32r/min |
| Diameter of Middle Mould | 26mm |
| Height of Middle Mould | 22mm |
| Diameter of up & Down Punch Pole | 22mm |
| Length of up & Down Punch Pole | 11mm |
| Production Capacity | 9600-13440pc/h |
| Motor | 0.75KW |
| Overall Size | 600X960X1150mm |
| Net Weight | 250kg |
Picture:
Rotary Tablet Press from this supplier
FOB Price: 11800.00-15800.00 USD/Set
Min Order: 1 Set
