Coconut Oil Tubular Centrifuge

FOB Price:	4500.00 - 10000.00 USD/Set
Supply Ability:	100 Set(s) per Year
Shipping:	SHIPMENT
Payment Terms:	T/T

In Stock

Inquiry Now Start Order

Product Details

Export Markets:	Eastern Europe, Southeast Asia, Western Europe
Packaging Details:	WOODEN PACKAGE

Quick Details

After-sales Service Provided: No overseas service provided
Voltage: 380V
Brand Name: LILONG
Type: Centrifuge
Condition: New
Warranty: ONE YEAR
Dimension(L*W*H): 1020x600x1558mm
Weight: 500KG
Power(W): 3.0KW
Model Number: GF/GQ150

Specifications

Tubular Centrifuge for Coconut Oil Separation

Virgin Coconut oil otherwise called as "mother of all oils" are extracted with the help of a centrifuge. this process is also called as cold processing method as there is not heat supplied for extracting oil.Oil extracted at temperatures below 80F is of the best quality and aroma. We offer you the tubular centrifuge machine that efficiently extract oil from coconut milk.

Process:

Coconut milk if fed at the inlet located at the bottom of the bowl. the bowl is connected to a motor and separation takes place inside the rotating bowl at a speed of 15,000 rpm.the basic principle is that the difference in densities of two immiscible liquids forces the liquid with higher density outside the rotation axis. the heavier liquid phase is forced towards the bowl while the light phase is force inside. Special openings at the top of the bowl separate Virgin Coconut Oil and water at two outlets at the top corresponding to the light phase which is water and the heavy phase which Virgin coconut oil. the Virgin coconut oil separated is further fed again into the centrifuge and repeated three times to get pure oil.

Application

this equipment serves the purpose of extracting Virgin Coconut Oil from coconut milk.the centrifuge marks the final stage in the process of extracting VCO and as the name implies centrifugal method is used for this process. A unique feature of this process is that it utilizes non heat method of extraction also called cold processing. Heated methods can destroy many vital nutrients that act as natural preservatives during storage. Cold processing technology retains oil's natural properties and nutritional values. All contact parts of the machine are SS304 which is resistant to corrosion and food safe.

Tubular Centrifuge for Coconut Oil Separation

Parameter of tubular centrifuge GQ/GF 150J
Inner diameter of bowl: 142mm
Solid holding capacity: 10 litres
Speed: 15570RPM
Centrifugal force: 15025 x G
Thoughput: 3000 litres per hour
Motor: 3.0 KW
Size: 1020x600x1558mm
Weight: 500kg
