Topccd Industrial Co., Ltd.
China Manufacturer with main products: TFT LCD Monitors, Backup Cameras, 360 Degree Vision System, 1080P MDVR, Radar Detection System, Wireless Backup Systems, Wi-Fi System,... |
Home
>Products Catalog > Cameras > Heavy Duty Mobile Vision Safety Rear View Safety CCD Camera from Topccd (TOP-15R)
Heavy Duty Mobile Vision Safety Rear View Safety CCD Camera from Topccd (TOP-15R)
| FOB Price: | 20.00 - 50.00 USD/Piece |
|---|---|
| Shipping: | express |
| Payment Terms: | T/T, Western Union, Other, Paypal |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | white boxes |
Quick Details
- Warranty: 1Years
- Brand Name: TOPCCD
- Car Make: Universal
- Voltage: DC 24V
- Type: Reverse Camera
- Model Number: TOP-15R
- Resolution: 500TVL,600TVL,700TVL,960P,10809P
- Waterproof: IP69K
- Viewing Angle: 170 degree
- IR LEDs: 12pcs
- More funcitons: Support normal/mirror image switching
- Microphone: Yes
- Built-in Heater: Yes
Specifications
. IP69K Waterproof 170 Wide View Angle CCTV CCD Cameras for Heavy Duty Trucks & Large Vehicles
. Model: TOP-15R
. Image Type: 1/3" NVP SONY CCD Sensor 500TVL,600TVL,700TVL Optional
1/4" SHARP CCD Sensor 420TVL
. Signal System: NTSC / PAL System optional
. Video System: Internal
. Viewing Angle: 170 (diagonal) / 150 (horizontal)
. Lens: 1.7mm
. Night Vision: 12pcs infrared LEDs
. Minimum Illumination: 0Lux (LED ON)
. White Balance: Auto
. Exposure Control: Auto
. Gain Control: Auto
. S/N Ratio: 48dB
. Video output: 1Vp.P 75ohm
. Waterproof resistance: IP69K
. Vibration Rate: 10G
. Built-in Microphone: Optional
. Builting Heater: Optional
. Sun shade: Yes
. Connectors: 4PIN or RCA optional
. Shell Material: Aluminous housing
. Casing colors: Black (White optional)
. Image: Mirror / non-Mirror image optional (Default Mirror image)
. Support Normal / Reversing image Switching: Optional
. Operating Temperature: -20~+75 RH95% Max.
. Storage Temperature: -30~+85 RH95% Max.
. Voltage Input: DC12V (DC12V/24V optional)
. Mounting: Suitable for all applications including buses,mini vans,caravans,trailers,trucks,agriculture equipment and much more
