Full automatic Aerosol filling machine line

FOB Price: 5000.00 - 35000.00 USD/Set
Supply Ability: 100 Set(s) per Month
Shipping: Shanghai Port
Payment Terms: D/P, T/T, Western Union
In Stock

Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Quick Details

  • Type: Filling Machine
  • Brand Name: FTK
  • Packaging Material: Glass,Metal,Paper,Plastic
  • Packaging Type: Bags,Barrel,Bottles,Cans,Capsule,Cartons,Case,Pouch,Stand-up Pouch
  • Application: Apparel,Beverage,Chemical,Commodity,Food,Machinery & Hardware,Medical,Textiles
  • Condition: New
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Weight: 1ton
  • Power: 0.75KW
  • Driven Type: Pneumatic
  • Automatic Grade: Automatic
  • Production Capacity: 30-50 tins/minute
  • Electric control box and heat pipe type: Blast proof type
  • Air Pressure: 0.3-0.6MPa
  • Maximum air consumption: 0.6m3/min
  • Applicable Tin Dia: 35-65mm
  • Applicable Tin Ht: 80-330mm
  • Air Filling Capacity: 50-750ml
  • Email: fetek.cindy@outlook.com

Specifications

Full automatic Aerosol filling machine line
This machine consist of cans arranging machine, rotary liquid filling machine, valve inserting machine, rotary sealing and gas filling , automatic weight checker, water bath, nozzle presser, cap presser, ink jet printer, packing table, etc. Propellants could be  N2, compressed air, etc, This machine also applied in Automotive aerosol production also spray paint, air freshener, insecticide, body spray, cosmetics, food aerosols.
Detailed Images
Full automatic Aerosol filling machine line

Specifications



Dimension(L*W*H) 18000*1800*1900mm Weight 200-500KG
Liquid volume: 50-1000ml(customized) Filling Capacity: 2400-3600cans/hour
Gas volume 50-750ml Voltage: 220V/380V
Filling Accuracy 99% above Diamter of cans 35-65mm
Application products
Full automatic Aerosol filling machine lineFull automatic Aerosol filling machine line
