PS9016 PID Intelligent Melt Pressure Controller

FOB Price: 180.00 - 220.00 USD/Set
Supply Ability: 1,000 Set(s) per Week
Shipping: 7-15 days CPT
Payment Terms: L/C, T/T, Western Union
In Stock
  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.


Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Sichuan in China
Packaging Details: standard carton

Quick Details

  • Max. Working Pressure: 0-150MPa
  • Max. Voltage: 1
  • Max. Current: 1
  • Brand Name: SAND
  • Operating Temperature: 85
  • Model Number: PS9016
  • Usage: liquid
  • Output: 2.0mv/v ,3.33mv/v
  • Theory: indicator
  • material: plastics
  • color: black

Specifications

Pressure Controller Introduction

     PS9016 series programmable intelligent digital pressure controller is the latest brand new pressure instrument.  It is especially suitable for melt pressure measurement and control areas with its superior compatibility and cost performance. And it can be used withPT series melt pressure sensor / transmitter to support the high-temperature melt, fluid, and the accurate measurement of gas pressure perfect control widely in Petrochemical, textile and chemical fiber, plastics, rubber, non-woven fabric, machinery and other equipment industries. It is with a full-featured, high reliability, stability, appearance, and strong anti-interference characteristics to ensure the long-term stability of the system work.



Pressure Controller Performance



1. Pressure range and decimal point location can be programmed;

2. Single PID pressure control signal output, providing multiple output signals (eg: 0~10V, 0~5V, 0~20mA, 4~20mA,), programmable;

3. Two alarm outputs, multiple alarm modes can be programmed;

4. Automatic calibration and panel error correction function;

5. Compatible with multiple pressure transducer and transmitter input signal;

6. Four digital displays with two layers and double colors and 20 segments electronic bar indicate the output power;

7. Provide RS485 computer communication interface (optional);

8. Triple combination of anti-jamming technology to ensure more accurate;

9. More than 20,000 hours of trouble-free operation;

10. with manual and automatic Switching feature to control output power.



Pressure Controller Technical Index

Pressure range

0~1500bar;0~20000psi

Power supply

85~265VAC;24VDC;110VAC;220VAC;240VAC

PID output signal

0~5V,1~5V,0~10V,0~10mA,0~20mA,4~20mA(Programmable )

Alarm

Two-way upper and lower limited relay alarm

Relay contact output

250VAC,5A

Input signal

2.0mV/V,3.33mV/V,0~20mA,4~20mA,0~10V,0~5V,1~5V

Communication

RS485

Mailing Address

0001~0255

Communication baud rate

2400bps,4800bps,9600bps,19200bps,38400bps

Inner resolution

32000

Ambient temperature

-10 C~50 C

Ambient humidity

<80%RH










Our Services

5 Year warranty (First two years are free to repair,other 3 years are chargeable)

OEM service available (Products supplied without any logo,you could put your own logo on it)

Technical support  (We are available to solve any problems you have on sensors any time)



PS9016 PID intelligent melt pressure controller
