Optical Booster EDFA 22dbm Output Power Adjustable 1550nm Erbium Doped Fiber Amplifier CATV

FOB Price:	445.00 - 1100.00 USD/Piece
Supply Ability:	1,000 Piece(s) per Month
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Product Details

Packaging Details:	Foam + Carton Package Each unit size: 545213cm 2pcs are packed in one big carton box Big carton box size: 555326cm

Quick Details

Type: Professional Amplifier
Brand Name: ZOOMFIBER
Frequency Response: 45-1000
Power Supply: 85~265VAC or -48 VDC
Warranty: 1
Model Number: ZOA1550A
Optical wavelength: 1540~1560nm
SNMP interface: RJ45, RS232

Specifications

(1) High quality: the former-class pump adopts 980nm, after-class pump adopts 1480nm, optical power is optimized by software to minimize noise figure of EDFA, and make systems achieve excellent CNR

(2) Flexibility: Power adjustable range -4~+0.5dBm, the machine built-in high-performance switching power supply, it can work at 85~265Vac City Network Voltage, as well as an optional DC48V power supply (reservations required); chassis cooling automatic temperature control.

(3) Intuitive: the machine equipped with microprocessor monitors the working state of the laser, the panel LCD window displays the operating parameters.

(4) Network type: Select All-piece status monitoring transponder guarantee to meet the national standard and be compatible with the SCTE HMS standard, it enables network management monitoring capabilities.

Items	unit	Specification
Operating wavelength range	nm	1540~1560
Optical input power	dBm	-10~+10
Nominal optical input power	dBm	3
Working pump quantity		1~3
Saturated output power	dBm	13~27
Output power adjustable range	dBm	-4~+0.5
Number of output ports	port	1~8 (customer specify)
Noise Figure (NF)	dB	<5.0 (+0 dBm input @1550nm)
Optical output power stability	dB	<0.5
Polarization Sensitivity	dB	<0.2
Polarization dependence gain	dB	<0.5
Polarization mode dispersion	ps	<0.5
Optical connector (in/OUT)		SC/APC or FC/APC or customer specify
SNMP network management interface (optional)		RJ45
Power supply	VAC	85~265VAC or -48 VDC
Power consumption	W	50
Working temperature	C	-5~65
Storage temperature	C	-40~80
Operating relative humidity	%	5~95
size	"	1914.51.75 (1U,19'')
Weight	Kg	5

Product series

Model	Optical output power
ZOA1550A-13	Saturated output power13dBm
ZOA1550A-14	Saturated output power14dBm
ZOA1550A-15	Saturated output power15dBm
ZOA1550A-16	Saturated output power16dBm
ZOA1550A-17	Saturated output power17dBm
ZOA1550A-18	Saturated output power18dBm
ZOA1550A-19	Saturated output power19dBm
ZOA1550A-20	Saturated output power20dBm
ZOA1550A-21	Saturated output power21dBm
ZOA1550A-22	Saturated output power22dBm
ZOA1550A-23	Saturated output power23dBm
ZOA1550A-24	Saturated output power24dBm
ZOA1550A-25	Saturated output power25dBm
ZOA1550A-26	Saturated output power26dBm
ZOA1550A-27	Saturated output power27dBm
