Tops Industry & Technology Co., Ltd.
China Manufacturer with main products: DC Micro Pump, Solar Heater Pump, Water Circulation Pump, Liquid Pump, Vacuum Pump, Air Pressure Pump, Cooling Pump, Gear Pump |
Home
>Products Catalog > Brushless Centrifugal DC Pump > Professional Supplier 12V 24V Mini Hot Water Centrifugal Circulation Pump
Professional Supplier 12V 24V Mini Hot Water Centrifugal Circulation Pump
| FOB Price: | 13.00 - 18.00 USD/Piece |
|---|---|
| Supply Ability: | 200,000 Piece(s) per Month |
| Shipping: | Delivery Time 20 day |
| Payment Terms: | T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hunan in China |
Quick Details
- Pressure: High Pressure
- Standard or Nonstandard: Standard
- Power: Electric
- Structure: Single-stage Pump
- Brand Name: TOPSFLO
- Usage: Water
- Theory: Centrifugal Pump
- Model Number: TL-B10
- Motor: dc brushless motor
- voltage: 12v 24v
- Max head: 8M
- Max flow: 12L
Specifications
Product Features:
1.AdvanceD magnetIc driving technology for static-seal, without any leakage forever
2.Durable permanent magnetic rotor with one-off injection incorporated impeller in smooth balance
3.Heavy duty work, can sustain Continuous 24 hours work
4.Special designed high efficiency closed-type impeller
5.Sustain 100C hot water circulation
6.All wetted materials FDA approved to be safety usage
7.Low or no maintenance
8.Can customized
Product Specification:
| Model | Product Code | Max Water Flow (L/Min) | Rated Voltage(DC) | Rated Current (A) | Max Water Head(M) | Rated Power(W) | |
| B10 | TL-B10-A12-0703 | 7 | 12VDC | 0.54 | 3 | 6.48 | |
| TL-B10-A24-0703 | 7 | 24VDC | 0.35 | 3 | 8.4 | ||
| TL-B10-B12-0703 | 7 | 12VDC | 0.54 | 3 | 6.48 | ||
| TL-B10-B24-0703 | 7 | 24VDC | 0.35 | 3 | 8.4 | ||
| TL-B10-C12-0703 | 7 | 12VDC | 0.54 | 3 | 6.48 | ||
| TL-B10-C24-0703 | 7 | 24VDC | 0.35 | 3 | 8.4 | ||
| TL-B10-A12-0905 | 9 | 12VDC | 1.38 | 5 | 16.56 | ||
| TL-B10-A24-0905 | 9 | 24VDC | 0.65 | 5 | 15.6 | ||
| TL-B10-B12-0905 | 9 | 12VDC | 1.38 | 5 | 16.56 | ||
| TL-B10-B24-0905 | 9 | 24VDC | 0.65 | 5 | 15.6 | ||
| TL-B10-C12-0905 | 9 | 12VDC | 1.38 | 5 | 16.56 | ||
| TL-B10-C24-0905 | 9 | 24VDC | 0.65 | 5 | 15.6 | ||
| TL-B10-A24-1208 | 12 | 24VDC | 1.3 | 8 | 31.2 | ||
| TL-B10-B24-1208 | 12 | 24VDC | 1.3 | 8 | 31.2 | ||
| TL-B10-C24-1208 | 12 | 24VDC | 1.3 | 8 | 31.2 | ||
Characteristics:
| Max Flow Rate | 7L/min 9L/MIN 12L/MIN |
| Max Static Lift | 3M 5 M 8 M |
| Rated Voltage | 12V / 24V |
| Impeller Type | Closed impeller |
| Motor Type | Brushless DC motor |
| Liquid Temperature | -40-100C |
| Ambient Temperature | -40-70C |
| Media | Pure Water,Beverage, antifreeze |
| Working Voltage Range | 6~18V or 12~28V |
| Power Consumption | 1~32W |
| Noise Class form 1M | 40dB /Max |
| Ideal Life Time | 20000 Hours |
| Working Mode | Continuous |
| Power Supply | DC power supply, battery |
| Protection Functions | 1. Polarity protection 2. Blocked protection |
| Remarks | Can't dry-running, not Self-priming |
Customized functions
|
1.PWM, 0~5V speed control, 2.Submersible 3.Solar panel driven directly 4.FG(RPM) signal wire |
the technical parameters above is only for your reference, for more details, please Feel free to | |
Typical Applications
Household battery water pump Water dispenser, Water Coolers
Automotive air conditioning Carbonation, Coffee Maker, Beverage Dispenser
Air-conditioner Drain Chillers, Cooling Circulation,
Home Appliance Boosting Evaporative coolers
Get More technical parameters, please Feel to
