>Products Catalog > 12 Years PCB&PCBA Factory SMT DIP Bare Pcb & Electronic Components Assembly One-Stop Service
12 Years PCB&PCBA Factory SMT DIP Bare Pcb & Electronic Components Assembly One-Stop Service
| FOB Price: | 2.00 - 25.00 USD/Piece |
|---|---|
| Supply Ability: | 10,000 Piece(s) per Week |
| Shipping: | express, air,sea |
| Payment Terms: | T/T |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Western Europe |
|---|---|
| Place of Origin: | China |
| Packaging Details: | anti static bag+carton |
Quick Details
- Surface Finishing: HASL
- Board Thickness: 1.6
- Copper Thickness: 0.5oz-6oz
- Base Material: FR-4
- Brand Name: Grandtop / OEM
- Min. Line Spacing: 3 mil
- Min. Line Width: 3mil
- Min. Hole Size: 0.1mm
- Model Number: PCBA 002
- Item: PCB&PCBA factory SMT DIP bare pcb and electronic components assembly one-stop service
- keywords: Pcb Assembly services
- other keywords: PCB assembly manufacturer
Specifications
12 years PCB&PCBA factory SMT DIP bare pcb and electronic components assembly one-stop service
Article |
Description |
Capability | |
Sercive |
PCB and SMT assembly with one-stop service | ||
Material |
Laminate materials |
FR4, high TG FR4, high frequency, alum, FPC | |
Board cutting |
Number of layers |
1-48 | |
Min.Thickness for inner layers (Cu thickness are excluded) |
0.003" (0.07mm) | ||
Board thickness |
Standard |
(0.1-4mm10%) | |
Min. |
Single/Double:0.0080.004" | ||
4layer:0.010.008" | |||
8layer:0.010.008" | |||
Bow and twist |
No more than 7/1000 | ||
Copper weight |
Outer Cu weight |
0.5-4 0z | |
Inner Cu weight |
0.5-3 0z | ||
Drilling |
Min size |
0.0078" (0.2mm) | |
Drill deviation |
0.002(0.05mm) | ||
PTH hole tolerance |
0.002(0.005mm) | ||
NPTH hole tolerance |
0.002(0.005mm) | ||
Solder mask
|
Color |
Green,white,black,red,blue | |
in solder mask clearanace |
0.003(0.07mm) | ||
Thickness |
(0.012*0.017mm) | ||
Silkscreen |
Color |
White,black,yellow,blue | |
Min size |
0.006(0.15mm) | ||
E-test |
Function Test |
100% Functional test | |
PCBA Testing |
X-ray,AOI Test,Functional test | ||
PCB assembly |
One-stop service electronic manufacxturer service | ||
Component sourcing |
Yes | ||
Certificate |
IATF16949,ISO9001 | ||
Delivery time: |
PCB |
3-8days | |
PCBA |
10-20days | ||
Tolerance of PCB |
5% | ||
Max size of finish board |
700*460mm | ||
MOQ |
NO MOQ (1pcs) | ||
Surface Finish |
HASL,ENIG,immersion silver,immersion tin,OSP | ||
PCB outline |
Square,circle,irregular(with ) | ||
Package |
QFN,BGA,SSOP,PLCC,LGA | ||
Sub-assembly |
Plastic,metal,screen | ||
1,What service do you have?
We are OEM PCB and PCBA manufacturer,provide turnkey solutionincluding PCB fabrication,SMT and assembly PCBA inside the enclosure,Functiontesting and other value-added service.
2,What are the main products of your PCB/PCBA services?
OuR Services are mainly for the industries including Industrial Control Medical,Automotive,Communication,Smart home,Safety protection.
3,What files required to get quotation from you?
for PCB, please provide the Gerber data/files and indication of related technical requirements as well as any special requirement if you have.
for PCBA(PCB with soldered components),please Provide Gerber files and also BOM (Components list), and if you need us to do function test, please also provide the test instruction/procedure.
4,how long does it take for PCB and PCBA Quote?
PCBs quotation within 2 hours can finished.
the PCBA depend on the components quantity,if you order is urgently please contact us directly,we will priority to deal it and do ourbest to give you satisfied delivery time.
5,how to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
6,Can we inspect quality during production?
Yes, we are open and transparent on each production process with nothing to hide. We welcome customer inspect our production process and check in house.
7,how about the delivery?
Normally, for sample order, our delivery is about 5 days.for small batch, our delivery is about 7days. for mass production batch, our delivery is about 10 days,but that depends on the real condition when we get your order.If your order is urgently please contact us directly ,we will priority to deal it and do ourbest to give you satisfied delivery time.
8,Do you have any minimum order quantity (MOQ) requirement?
No, we do not have MOQ requirement, Sample and mass production all can support.
