LCK-10 Silicone Pad High-Performance Insulating Material
| FOB Price: | 0.01 - 0.20 USD/Piece |
|---|---|
| Supply Ability: | 100,000 Piece(s) per Week |
| Shipping: | DHL UPS EMS FEDEX |
| Payment Terms: | T/T, Western Union, MoneyGram |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | roll form/ sheet form, die-cut parts; customized size available. With or without adhesive available. |
Quick Details
- Rated Voltage: 7.0KV/mm
- Application: High Temperature
- Material: Composite Polymer
- Type: Insulation Sheet
- Brand Name: LTD
- Tensile Strength: MPa
- Model Number: LCK-10
Specifications
LCK-10 Silicone Pad
Features & Benefits:
L Heat emission, insulation, fire prevention, shock resistance.
L Thermal impedance: 0.41-in2/w(50psi)
L Breakdown voltage can reach at 7000V
L Designed for the substitutes of the ceramic insulators
Typical Applications:
L Heating power components; Automobile electronic heating module; Power module; Household appliances;
Physical Properties:
Test Item |
TEst Method |
Unit |
LCK-10 Test Value |
Color |
Visual |
- |
Yellow |
THickness |
ASTM D374 |
mm |
0.15 |
Specific Gravity |
ASTM D792 |
g/cm3 |
2.00.1 |
HArdness |
ASTM D2240 |
Shore A |
755 |
TEnsile Strength |
ASTM D412 |
Mpa |
29 |
Continuous Use Temp |
EN344 |
-50+200 | |
BReakdown Voltage |
ASTM D149 |
KV |
7.0 |
VOlume Resistivity |
ASTMD257 |
cm |
1.01014 |
Flame Rating |
UL94 |
- |
- |
Thermal Conductivity |
ISO 22007-2 |
W/mK |
1.3 |
Specification: roll form/ sheet form, die-cut parts; customized size available.
with or without adhesive available.
for more, please feel free to contact us.
