Pleated PP Depth Filter Cartridges with High Dirt-Holding Capacity
| FOB Price: | 3.00 - 8.00 USD/Piece |
|---|---|
| Shipping: | FOB Shanghai |
| Payment Terms: | T/T |
Related products from verified members
| Export Markets: | North America, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | poly bag first, then inner box, at last into outer carton |
Quick Details
- Brand Name: YW
- Condition: New
- Medium Material: propylene
- Certification: as you require
- Weight: 0.28kg/10"
- Micron Rating: 1, 3, 5
- Length(inch): 10, 20, 30, 40
- Connection: 222+Flat, 222+Fin, 226+Fin, DOE
- O-Rings/Gaskets: Silicon, EPDM, Viton
- Material: propylene
Specifications
PPD Depth Filter has Been developed for a wide variety of general process applications from fluid Clarification to general prefiltration. Its high dirt-loading, random fiber Polypropylene depth media provides consistent particle retention. the Depth Filter is thermally bonded from 100% virgin polypropylene to ensure clean Filtrates and excellent chemical and thermal compatibility in the most Demanding processing conditions.
Broad chemical compatibility allows use in most applications
Thermally bonded construction minimizes extractables for Cleaner filtrates
Beverage/wine clarification.
M
Media Layer: Polypropylene
Support Layer:
End Caps/Core/Cage: Polypropylene
O-Rings/Gaskets: Silicon, EPDM, Viton
: 1, 3, 5
Length(inch): 10, 20, 30, 40
Connection: 222+Flat, 222+Fin, 226+Fin, DOE
Operating Conditions
Max. Running temperature: 70
Max. Allowable Differential Pressure: 5Bar(20), 2Bar(80)
Max. Allowable Back Pressure: 2Bar(20)
Inline Steaming Sterilize:121, 30min@max differential pressure of 0.5 bar up to 25 times
Hot water sanitization: 85 40 minutes up to 100 times
Chlorine sanitization: 50 ppm up to 1000 hours at 25
Ordering Information
Micro Rating |
Connection |
Length |
Gasket |
| |
10=1m |
0=222+Flat |
1=10 |
S= Silicon |
| |
30=3m |
5=222+Fin |
2=20 inch |
E= EPDM |
| |
50=5m |
7=226+Fin |
3=30 inch |
V= Viton | ||
F=DOE |
4=40 inch |
||||
