8mm 2/3" 10M FA Machine Vision Lenses CCTV Face Recognition Industrial Low Distortion Camera Lenses Baumer Basler Hik

FOB Price:	1.00 - 100.00 USD/Piece

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangxi in China

Quick Details

Brand Name: SOYO
Focal Length: 8mm
Material: Alluminum
Iris: Fixed
Focus: Manual
Model Number: SMV0824-10M

Specifications

the following example is for you reference.

Main Advantages: High quality, big format 2/3", low distortion; tested and qualified by Hikvision, Baumer, Basler etc.

Technical details: over 10G and aspherical

FA Lens Features:

High resolution: 10 megapixel cover all 4K & 1080P
Large format: 2/3" size covering 2/3", 1/1.8", 1/2" camera
Big aperture: F2.4 big aperture makes imaging far better
Low distortion: <1.1% low distortion use machine vision ITS
Compact size: 38Mm diameter compact size
Illumination: 67%
Application : Automation, machine vision, medical, life science, ITS, SMT, AOI.

Model		SMV0824-10M
Resolution		10 Megapixel
Format		2/3"
Focal Length (mm)		8mm
B.F.L (mm)		9.3mm
Aperture (Close)		F2.4 Manual iris
Angle of View ()	2/3"	*69.558.245.2*
	1/2"
	1/3"
M.O.D (m)		0.1m
Size		*3847**
Distortion		1.1%
Filter Size (mm)		*M370.5**
Mount		C
Weight (g)		100
