Access Control Special Keypad ABS USB Plastic Customized 3X4 Matrix Keypad

Supply Ability: 100,000 Piece(s) per Day
Shipping: NINGBO/SHANGHAI
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Safebuy, Other
  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.


Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Packaging Details: 43CM X 38CM X 12CM / Piece/Pieces 0.2KG / Piece/Pieces

Quick Details

  • Keypad Button Material: Plastic
  • Application: Telecommunication Equipment
  • Brand Name: SINIWO
  • Style: 3X4 matrix keypad
  • Interface Type: Pins header/XN Plug/PS2/DB9/USB
  • Model Number: b110
  • Material: ABS plastic
  • Style: Matrix Keypad
  • Connection: Pin Header,XH plug,USB,PS2,RS232
  • Certificate: CE,ISO9001
  • Levels of Protection: IP66
  • Vandal Resistence: YES
  • Application: for testing machine
  • Button Life: 1 miilon
  • Keys: 3x4 12 keys

Specifications

Access control special keypad ABS USB plastic customized 3X4 matrix keypad
P
PRODUCT DESCRIPTION


APPLICATION

Self-service library

Self-service kiosk

CNC machine

Household applications

Oiling machine

Charge spot

Industrial telephone

ATM

Access control

Ticket machine

Vending machine

Medical facility

Security system

Fingerprint attendance machine




PARAMETERS

Model number

B110

Defend Grade

IP65

Keys

16 keys

Vandal resistant

IK09

Electrical lifetime

> 5 years

Contact resistance

200 ohm (max)

Current Rating

Appr. 45mA

G.W.

0.100kg approx

Dimensions

64mm *51mm*11mm

Frame/keys materials

Plastic

Life span

 500,000

Elasticity of key

2.5-3N

Key Stretch

180-200g

Travel Distance

2mm

Atmospheric pressure

60-106Kpa

Operate Temperature

-25~+65


Access control special keypad ABS USB plastic customized 3X4 matrix keypad
