Dongguan Zeguan Machinery Co., Ltd.
China Manufacturer with main products: Aluminum Cutting Machine, Aluminum Sawing Machine, Steel Pipe Cutting Machine, Aluminum Angle Cutting Machine, Aluminum Profile 45 Degree... |
Home
>Products Catalog > Disc Angle Cutting Machine, Aluminum Frame Cutting Machine, Rotary Plate Type Angle Sawing Machine
Disc Angle Cutting Machine, Aluminum Frame Cutting Machine, Rotary Plate Type Angle Sawing Machine
| FOB Price: | 7200.00 - 7500.00 USD/Piece |
|---|---|
| Payment Terms: | T/T |
Related products from verified members
| Place of Origin: | Guangdong in China |
|---|
Quick Details
- After-sales Service Provided: No overseas service provided
- Condition: New
- Brand Name: ZEGUAN
- Weight: 530
- color: blue
- Model Number: ZG-410SA
Specifications
Suitable for
Cutting all kinds of nonferrous metal, aluminum, aluminum alloy, copper, copper
Alloy, plastic material, plastic, PVC, wood, organic glass (acrylic) and carbon
Fiber materials, especially suitable for copper and aluminum electronic
Components, radiator, audio panels, graphics CARDS, network CARDS, CPU, hard
Disk aluminum shell, MP3 shell, aluminum doors and Windows, picture frames,
Light boxes, screen, display equipment, line type lamp, aluminum furniture,
Aluminum extrusion and precision cutting of different profile
1, accurate Sawing Angle, high precision, smooth cutting surface without burr, high Efficiency.
2, only foot Switch, automatic mechanical pressure, automatic saw material is safe and easy
3, hidden saw Blade from the bottom up sawing, sawing single or multiple materials at the Same time
4, the pressing System is driven by precise linear sliding track and controlled by independent Air pressure cylinder, with high stability of pressing material (the pressure Can be adjusted independently according to the material type to prevent Material damage caused by heavy pressure)
5, press height and speed and saw cutting height and speed can be set according to material Size and thickness.
6, precision Forced oil injection system, improve lubrication and cooling effect, reduce Failure rate and prolong blade life
7, can do 0~45 degrees arbitrary Angle saws, Angle adjustment convenient and accurate
Model |
ZG-410SA |
Sawing angle |
+45 ~ 0~ -45 |
Blade size |
16"x1" Inner hole |
Saw blade |
3200R.P.M. |
Machine motor |
3 HP |
Pressure required |
4-6kg/cm2 |
Size of Table |
800x400mm |
Table height |
850mm |
NW/GW |
500 /530kgs |
Machine dimension ( LxWxH ) |
1100x1000x1600mm |
Packing dimension ( LxWxH ) |
1200x1100x180mm |
