Home  >Products Catalog > Glass Fibre Fiberglass Braided Sleeve for Hose Protection

Glass Fibre Fiberglass Braided Sleeve for Hose Protection

FOB Price: 1.00 - 10.00 USD/Meter
Supply Ability: 100,000 Meter(s) per Day
Shipping: by sea, by air, by express
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Safebuy, Other, CASH
In Stock
  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.


Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Anhui in China
Packaging Details: CARTON BOX

Quick Details

  • Rated Voltage: 0
  • Application: High Temperature
  • Material: Fiberglass
  • Type: Insulation Sleeving
  • Brand Name: PAKE
  • Tensile Strength: HIGH
  • Model Number: FGS
  • ID: 1-150mm
  • Thickness: 1-3mm
  • Color: White
  • Material: Fiberglass

Specifications

FGS braided fiber glass sleeve or fibre glass tubing is braided by high quality fiberglass, and resist most acids and alkslis. this sleeve is highly flexible and conformable. It is avaiiable with 1.0 mm, 1.5mm, 3.0mm thickness.


Features

It is resists most acids and alkalis and is unaffected by most bleaches and solvents.  It is highly flexible and conformable.

this braided glass fiber sleeve capable of operating at a continuous temperature of 1000°F (538°C).


Application

It provides excellent protection for industrial wires, cables, hoses (hydraulics), tube and pipes and also provides thermal insulation and personnel protection.


Specifications

Part Number Normal Inside diameter Meter for spool
Inches mm Dash # Meter
FGS-06 1/4 6 -4 50
FGS-08 5/16 8 -5 50
FGS-10 3/8 10 -6 50
FGS-11 7/16 11 -7 50
FGS-13 1/2 13 -8 50
FGS-16 5/8 16 -10 50
FGS-19 3/4 19 -12 50
FGS-22 7/8 22 -14 50
FGS-25 1 25 -16 50
FGS-29 1 1/8 29 -18 50
FGS-32 1 1/4 32 -20 50
FGS-35 1 3/8 35 -22 50
FGS-38 1 1/2 38 -24 50
FGS-41 1 5/8 41 -26 50
FGS-44 1 3/4 44 -28 50
FGS-48 1 7/8 48 -30 50
FGS-51 2 51 -32 50
FGS-57 2 1/4 57 36 50
FGS-60 2 2/5 60 -38 50
FGS-64 2 1/2 64 -40 50
FGS-67 2 5/8 67 -42 50
FGS-70 2 3/4 70 -44 50
FGS-73 2 7/8 73 -46 50
FGS-76 3 76 -48 50
FGS-83 3 1/4 83 -52 50
FGS-89 3 1/2 89 -56 50
FGS-95 3 3/4 95 -60 50
FGS-102 4 102 -64 50
FGS-114 4 1/2 114 -72 50
FGS-121 4 3/4 121 -76 50
FGS-127 5 127 -80 50
FGS-152 6 152 -96 50
Technical Datasheet
Material Fiberglass
Working temperature -40 - +260
Flammability VW-1
Melting point +550
Standard Color White
MOQ 200 meter each size
Cutting tool Scissors

Notes:
Special thickness, length or packing upon request.
Part nymber will be "-1.0" for 1.0 mm thickness" -1.5" for 1.5 mm thickness, " -3" for 3 mm thickness
Glass Fibre Fiberglass Braided Sleeve for hose protection
