China Hand Held Stainless Steel Laser Welding Machine

FOB Price: 20000.00 - 25000.00 USD/Set
Supply Ability: 1,000 Set(s) per Year
Shipping: By sea
Payment Terms: L/C, T/T
In Stock

Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Shandong in China
Packaging Details: Wooden Package; Qingdao Port

Quick Details

  • After-sales Service Provided: Engineers available to service machinery overseas
  • Certification: CE,ISO,SGS
  • Usage: carbon steel,stainless steel
  • Brand Name: Pioneer Laser
  • Voltage: 380v
  • Warranty: 1 year
  • Power(W): 2.2kw
  • Dimensions: 150x90x110mm
  • Max. Output Power: 1500w
  • Focal Spot Diameter: 0.3~1.5mm
  • Wavelength: 1064nm
  • Pulse Width: 0.3~20ms
  • Single Pulse Energy: 80J / 100J / 120J
  • Model Number: PW-1000
  • Condition: New
  • Laser Power: Raycus 1500w
  • Torch cable: 10m


China Hand  Held Stainless Steel Laser Welding Machine
laser welding machine
Model PW-1000w handheld laser welding machine adopts the latest generation of fiber lasers and is equipped with a self-developed wobble welding head to fill the blank of hand-held welding in the laser equipment industry. It's widely used in welding thin metal plates such as stainless steel plates, iron plates and galvanized plates with its advantages of simple operation, good-looking welding line, fast welding speed, and no consumables. Compared with traditional hard optical output system, it can increase the degree of processing freedom, and can simultaneously process multiple beams and multiple stations. Machining provides conditions for more precise welding. It can perfectly replace traditional argon arc welding and electric welding.

Mainly apply for welding of sheet metal, metal and aluminum alloy, used in household appliances, advertisement, module industrial, stainless windows and doors, handiwork, automobile spare parts industry. Automobile, aviation, aerospace, shipbuilding, power battery, hardware, and kitchenware, etc.
laser welding
Technical Parameters

Name Details
Model PW-1000 handheld laser welding machine
Laser power 1000w
Laser wavelength 1070nm
Fiber Length 15m
Working Mode Continuous/Pulse
Welding speed 0-120mm/s
Water cooling Industrial water cooling
Environment temperature 15°-35°
Humidity range <70%
Welding thickness 0.5-3mm
Voltage 380v

Advantages of handheld laser welding machine
1. Output fiber laser power stability, electro-optical conversion rate up to 30%, Its conversion rate is
    8 times of YAG.
 2. Beam quality is excellent, non-Gaussian light, multi-module fiber transmission.
3. Maintenance-free operation.
4.Low cost of use, almost no consumptive material, daily maintenance-free, reducing the cost of
    debugging when production line stops.
5. Long lifetime, high precision, pump source lifetime more than 100,000 hours.

Q: how to operate the machine? Is training necessary?
A: the machine is mainly controlled by software. It's very easy, not complicated. Before shipment, we will make a simple operation manual with pictures and provide a user manual of software. Generally speaking, an operator, who is not familiar with the fiber laser printing machine before can still operate it very well. According to customers' requests, we can send our technician to a customer' plant for machine training or customers can come to our plant for machine training if needed.
Q: in case a machine exists the problem, how to do after-sales service?
A: We provide two years of machine warranty. during the two-year warranty, in case of machine exists the problem, we will provide parts required with free of charge by express. but as for the parts damaged by artificially, it does not fall on our warranty list. after the warranty, we still provide lifetime service.
Q: What's the package?
A: We have 3 layers package. for the outside, we adopt the plywood case. in the middle, the machine is covered by foam, to protect the machine from shaking. for the inside layer, the machine is covered by the waterproof plastic bag.
Q: What's the delivery time?
A: Generally speaking, the lead time is 5-7 working days after receiving the payment.
Q: Can we add a protection cover?
A: Yes, we can add a protection cover if you need it. We can customize the design as customers' requests.
Q: What're consumables for fiber laser marking machine?
A: It does not have consumable. It's very economical and cost-effective.
