MMQ-02G High Temperature Atmosphere Friction & Wear Testing Machine
| FOB Price: | 27000.00 - 30000.00 USD/Set |
|---|
Related products from verified members
Quick Details
- Usage: material
- Power: farmar
- Brand Name: jinanyihua
- Warranty: //
- weight: //
Specifications
1. Description
the machine is mainly used for evaluating the friction and wear performance of various metals, coatings, engineering plastics, ceramics and new materials such as powder metallurgy under high temperature and different environmental atmospheres.
Sliding friction can be used to perform bolt-disc or ball-disc tests under various conditions such as changing load, speed, time, friction mate material, surface roughness, hardness, test environment temperature and other parameters. The testing machine has the expansion space of friction pair, which can be customized according to the needs of other forms of friction pai.
this machine adopts servo motor loading system, easy to operate and high precision. the computer controls the spindle speed, revolution, test time and other parameters. during the test process, the test force, speed, revolution, friction torque, friction coefficient, temperature, time and other parameters can be collected and calculated in real time. The corresponding test curve can be drawn.
2.Main technical specifications and technical parameters
No. |
Project items |
Technical index |
1 |
Loading range of test force |
0.1N-20N 20N-200N |
2 |
Relative Error of Test Force |
±1 |
3 |
Maximum friction |
100N |
4 |
Relative error of frictional force indicatione |
±2% |
5 |
Friction display resolution |
0.1N |
6 |
Spindle speed range |
5-2000r/min |
7 |
Spindle speed accuracy |
|
Errors below 100r/min and 100r/min |
≤±1 r/min | |
Error when spindle speed is above 100 r/min |
≤±5 r/min | |
8 |
Heating range |
at room temperature - 1000℃ |
9 |
Temperature control accuracy |
≤±2℃ |
10 |
the test medium |
Dry friction, oil lubrication, water and other media and N2, CO2, He and other inert gases |
11 |
Test machine time display control range |
0-999999999s/min |
12 |
Display and control range of revolution of test machine |
0-999999999r |
13 |
Spindle motor |
1Kw 4.77Nm |
14 |
Diameter of friction |
10-35mm is adjustable |
15 |
Test machine control mode |
Microcomputer control |
