Hubei Sunfleet Intelligent Equipment Co., Ltd.

China Manufacturer with main products: Dump Trucks, Concrete Mixer Trucks, Wrecker Trucks, Oil/Water Tank Trucks, Sanitation Trucks, Truck Axles, Truck Engines, Truck Parts

Home >Products Catalog > Dump trucks / Concrete mixer trucks > Dongfeng T-Lift Series 10 Wheel Cement Mixer Truck, 8cbm Mixing Drum, 6x4 Concrete Mixer Truck, Eu3, Eu4, Eu5 Emission Option

Dongfeng T-Lift Series 10 Wheel Cement Mixer Truck, 8cbm Mixing Drum, 6x4 Concrete Mixer Truck, Eu3, Eu4, Eu5 Emission Option

FOB Price:	30000.00 - 60000.00 USD/Unit
Supply Ability:	300 Unit(s) per Year
Shipping:	shipping
Payment Terms:	T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Packaging Details:	No packing

Quick Details

Gross Vehicle Weight: 25000
Brand Name: dongfeng
Aftersales service: 1 year
Leading time: 30 days
Test operation: factory test
Model Number: 5258G
Max mixing cubage: 8 cbm
Eu3 engine: cummins L340-33
Eu4 engine: cummins ISL340-40
Eu5 engine: cummins ISL8.9-340E51

Specifications

Basic Specification Parameter
Model	HXF5258G
1,Basic Parameter
Overall Length/Width/Height (mm):	10300x2500x3950
Curb Weight (kg):	14500
Chassis Brand and Model:	Dongfeng KC DFH1258G
Wheelbase(mm):	3650+1350
Front / Rear overhang (mm):	1500 / 2150
Approach / Departure Angle:	20-/13-
Front / Rear wheel distance (mm):	2040 /1860

2, Chassis Specification
Engine:	Dongfeng Cummins ISL8.9-340E51, L340-33 option
Engine Type	Line cylinder, Water cooling, Turbo
Max HP and Power (km/rpm)	340HP, 250KW
Engine Displacement:	8900ml
Fuel Type:	Diesel
Emission Level:	Euro 5
Gearbox Model:	Fast 12JS160TA
Gear Specification:	12 advance gear, 2 reverse gear
Carframe Specification:	300/90/8+6
Carframe Section Height:	300mm
Section Width:	90mm
Section Thickness:	8+6
Front Axle Description:	Forge steel beam axle, tandem axle, H shape beam section
Front axle load(kg):	6500
Rear Axle Description:	Hub reduction tandem drive axle, Cast steel axle case, with speed differential lock, with ABS
Rear axle load(kg):	26000
Rear axle speedratio:	5.26
Suspension Spring Type:	Multi leaves steel plate spring
Suspension Spring Specification:	Front 9 leaves, Rear 13 leaves
Brake system:	Service brake: Duo loop air brake, steel tube with dryer
Brake system:	Parking brake: Cut-off air brake
Steering system:	Hydraulic power steering
Fuel Tank Cubage:	350L
Tyre Qty:	10 wheels
Tyre Specification:	11.00R20 18PR

3, Modification Describtion
Mixer drum material:	Alloy steel plate, thickness:5mm
Geometric volume of mixer drum:	12 CBM
Max mixing cubage:	8 CBM
Feeding speed:	≧3 CBM
Discharging speed:	≧3 CBM
Leftover Rate:	≤0.3%
Max ratating speed of mixer drum:	14-16 (r/min)
Mixer drum obliquity:	5-10 Degree
Mixer drum diameter:	2200mm
Speed reducer:	PMP/WPM/ZF/BONFIGLIOLI
Hydraulic pump:	SAO
Hydraulic motor:	SAO
Water supply mode:	Water pump
