Large Diameter Galvanized Steel Corrugated Culvert Drainage Pipe

FOB Price:	70.00 - 800.00 USD/Meter
Supply Ability:	8,000 Meter(s) per Month
Shipping:	by sea
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

PP-R Fiber Pipe

Price:

Min. Order:
Oil Line Pipe

Price:

Min. Order:
Square Hollow Section

Price:400.00-700.00 USD/Metric Ton

Min. Order:20 Metric Ton
Welding Steel Pipes

Price:

Min. Order:

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	pallet

Quick Details

Section Shape: Round
Outer Diameter: 500-12000 mm
Thickness: 3-10 mm
Grade: STPA22-STPA26
Grade: STPA23
Standard: GB
Standard: GB/T 12771-2000
Outer Diameter: 0.5-12 meters
Alloy Or Not: Non-alloy
Special Pipe: Thick Wall Pipe
Surface Treatment: Galvanized
Technique: Cold Rolled
Application: Structure Pipe
Secondary Or Not: Non-secondary
Price: Factory

Specifications

Technical Specs:
1.Material of steel plate: Q235 steel plate

2.Thickness of steel plate:1.5mm-8mm

3.Shape: Round, Half, Arch,Oval ect.

4 Assembly:Annular flanged/Nestable

5 Depth of fill: 1.5-60m

6.Pipe Diameter: 300mm-9000mm

7.Corrugation: 68*13,100*20,150*50,200*55, 380*140,300*110,400*150

8.Antiseptic treatment: hot dip galvanized zinc ≥610g/m2.

9.Service life more than 70 years.

10:.Standard: JTT 791-2010 ,or AASHTO M36.

11.Application: storm water pipe,Traditional Culverts,Reline and Rehabilitation Solutions,Arch Bridges,Grade Separations,Wildlife Crossings,Pedestrian Underpasses,Stockpile Tunnels,Utilidors Conveyors Enclosures and many other applications

Steel Pipe specification

Limited Filling Height
Diameter (m)	the Thickness(mm)and correspondent Limited Filling height(m)
Diameter (m)	3	4	5	6	7	8	9	10
2	24.76	33.06	41.48	49.78	58.08	66.38	74.67	82.97
2.5	19.79	26.54	33.18	39.82	46.46	53.10	59.74	66.38
3	16.47	22.12	27.65	33.18	38.71	44.25	49.78	55.31
3.5	14.09	18.96	23.70	28.44	33.18	37.92	42.67	47.41
4	12.32	16.58	20.73	24.88	29.03	33.18	37.33	41.48
