>Products Catalog > 980nm/1030nm/1064nm Dual Stage High Power Optical PM Fiber Isolator 2W, 10W
980nm/1030nm/1064nm Dual Stage High Power Optical PM Fiber Isolator 2W, 10W
| FOB Price: | 1.00 - 100.00 USD/Piece |
|---|---|
| Supply Ability: | 50,000 Piece(s) per Month |
| Shipping: | Express |
| Payment Terms: | T/T |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | homemade |
Quick Details
- Brand Name: RUIK
- MOV: RUIK
- thermal fuse: RUIK
- Model Number: RUIK-PMI-006
Specifications
Parameters |
Unit |
Value |
Center Wavelength |
nm |
1064 or 1030 or 980 or 915 or 850 or 780 |
Operating Wavelength Range |
nm |
±5 |
Typ. Peak Isolation at 23℃ |
dB |
30 |
Min.Isolation at 23℃ |
dB |
25 |
Typ. Insertion Loss at 23℃ |
dB |
0.8 |
Max. Insertion Loss at 23℃ |
dB |
1.0 |
Max. Polarization Dependent Loss at 23℃,Only for PI |
dB |
0.15 |
Min. Extinction Ratio at 23℃,Only for PM |
dB |
20 |
Min. Return Loss(Input /Output) |
dB |
45 |
Max.AverageOptical Power |
W |
10 or Specified |
Max. Peak Power for ns Pulse |
kW |
10 or Specified |
Max. Tensile Load |
N |
5 |
Package Dimension |
mm |
58x28x26 |
Operating Temperature |
℃ |
+10~+50 |
Storage Temperature |
℃ |
0~+60 |
