Home >Products Catalog > 1310nm / 1550nm / 2000nm PM Optical Fiber Faraday Isolator

1310nm / 1550nm / 2000nm PM Optical Fiber Faraday Isolator

FOB Price:	1.00 - 100.00 USD/Piece
Supply Ability:	50,000 Piece(s) per Month
Shipping:	Express
Payment Terms:	T/T

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	homemade

Quick Details

Brand Name: RUIK
MOV: RUIK
thermal fuse: RUIK

Specifications

Parameter	Unit	Value
Stage	-	Single		Dual
Grade	-	P	A	P	A
Center Wavelength	nm	1310 or1550
Operating Wavelength Range	nm	±20
Typ. Peak Isolation at 23℃	dB	42	40	58	55
Min. Isolation at 23℃	dB	28	26	48	45
Typ. Insertion Loss at 23℃	dB	0.4	0.5	0.5	0.6
Max. Insertion Loss at 23℃	dB	0.55	0.65	0.65	0.8
Min. Extinction Ratio at 23℃(only for both Axis Working)	dB	20	18	20	18
Min. Extinction Ratio at 23℃(only forFast Axis Blocked) fa)	dB	25	23	25	23
Min. Return Loss (input/output)	dB	50/50
Max. Optical Power(CW)	mW	500
Max. Tensile Load	N	5
Operating Temperature	℃	-5~+70
Storage Temperature	℃	-40~+85

Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single-mode Fiber Components with ranging from 780nm to 2000nm. We also provide Customized components to our customers.

High power Optical Fiber Components:
-Optical Fiber Isolator, up 100W;
-Free Space Isolator, up to 100W;
-Optical Circulator, up to 30W;
-Pump Laser Protector;
-Band Pass Filter;
-Nx1 Pump Combiner;
-Cladding Power Stripper;
-Mode Field Adapter;
-(N+1)x1 Pump & Signal Combiner, 200W/port;

Polarization Maintaining Fiber Components:
-in Line Polarizer/Depolarizer;
-in Line Faraday Isolator;
-Optical Circulator;
-Fused WDM / Coupler;
-Filter WDM / Coupler;
-Fiber DWDM
-Fiber Mirror;
-Faraday Rotator;
-Fiber Patch cord / Jumper;
-PLC Splitter Module;
-Tap / WDM / Isolator Hybrid;
Manual Variable Optical Attenuator;
-1x2 Polarization Beam Splitter / Combiner (PBS/C)
-1x2 Isolator & Polarization Beam Splitter / Combiner (IPBS/C)

1310nm 1550nm 2000nm PM Optical Fiber Faraday Isolator
