1064nm PM Optical Fiber Faraday Isolator

FOB Price:	1.00 - 100.00 USD/Piece
Supply Ability:	50,000 Piece(s) per Month
Shipping:	Express
Payment Terms:	T/T

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	homemade

Quick Details

Brand Name: RUIK
MOV: RUIK
thermal fuse: RUIK

Specifications

Parameters	Unit	Value
Center WAvelength	nm	1310 or 1550	1064
OperatingWavelength Width	nm	±15	±5
Max. Insertion Loss	dB	0.6	3.0
Faraday Rotation Anglefor CWL	deg	45
Max. Rotation Angle Tolerance at 23 ℃ for CWL	deg	±3
Min. Extinction Ratio at 23 ℃, only for PM	dB	20
Max. Polarization Mode Dispersion	ps	0.05
Max.Power Handling	mW	500
Max. Tensile Load	N	5
Operating Temperature	℃	-5~+70
Storage Temperature	℃	-40~+85

Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single-mode Fiber Components with ranging from 780nm to 2000nm. We also provide Customized components to our customers.

High power Optical Fiber Components:
-Optical Fiber Isolator, up 100W;
-Free Space Isolator, up to 100W;
-Optical Circulator, up to 30W;
-Pump Laser Protector;
-Band Pass Filter;
-Nx1 Pump Combiner;
-Cladding Power Stripper;
-Mode Field Adapter;
-(N+1)x1 Pump & Signal Combiner, 200W/port;

Polarization Maintaining Fiber Components:
-in Line Polarizer/Depolarizer;
-in Line Faraday Isolator;
-Optical Circulator;
-Fused WDM / Coupler;
-Filter WDM / Coupler;
-Fiber DWDM
-Fiber Mirror;
-Faraday Rotator;
-Fiber Patch cord / Jumper;
-PLC Splitter Module;
-Tap / WDM / Isolator Hybrid;
Manual Variable Optical Attenuator;
-1x2 Polarization Beam Splitter / Combiner (PBS/C)
-1x2 Isolator & Polarization Beam Splitter / Combiner (IPBS/C)

1064nm PM Optical Fiber Faraday Isolator
