Shandong Yahui Machinery Equipment Manufacturing Co., Ltd.

China Manufacturer with main products: Rebar Cutting Machine, Rebar Bending Machine, Belt Vulcanizing Machine, Water Mist Fog Cannon Machine, Rubber Track Chassis, Road Cutting...

Home >Products Catalog > Rubber belt vulcanizing machines > Rubber Conveyor Belt Frame Type Vulcanizing Machine Conveyor Belt Vulcanizing Machine Rubber Belt Splicing Vulcanizing p

Rubber Conveyor Belt Frame Type Vulcanizing Machine Conveyor Belt Vulcanizing Machine Rubber Belt Splicing Vulcanizing p

FOB Price:	2000.00 - 20000.00 USD/Set
Supply Ability:	50 Set(s) per Month
Shipping:	Qingdao Port,Shanghai Port,etc
Payment Terms:	L/C, D/P, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	packed in wooden case

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 12months
Voltage: Three phase 220VAC/380VAC 415VAC or customized
Brand Name: YH
Condition: New
Certification: ISO9001
Weight: 800KGS
Dimension(L*W*H): 1700mm*830mm*750mm
Power(W): 10.80KW
Model Number: YH1200
belt width: 1200mm

Specifications

Conveyor belt vulcanizing machine,also called rubber belt splicing vulcanizing press is mainly used to industries for splicing and repairing for conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry, tobacco,and food automatic line field.
Features of Conveyor belt vulcanizing machine
1.Machine Maximum size: from 300MM-6000MM;
2.Voltage: 220V 380V 415V 660V 50HZ;
3.Fast Cooling time: 15 minutes (from 145 degrees down to 70 degrees or less);
4.Time for temperature raise (from normal temperature to vulcanizing temperature) no more than 25 minutes;
5.the temperature difference of sulfide surface: ±2°c.
6.Temperature adjustment range: 0~300°c.
7.Vulcanizing pressure: 0~2.5 MPa (details refer to users' specifications and factory markings);
8.Time of heat preservation for vulcanizing could be adjusted according to thickness of the rubber belts;
9.Splicing length of rubber conveyor belt for vulcanizing jointing could be connected together by single or several pieces if necessary;
10.Rubber conveyor belt as well as tension in kilogram required for vulcanizing jointing when ordering products.
11.Users could order spare electric pumps additionally according to requirements.
Any questionsof belt vulcanizing machines,please contact with lucy cell/wechat/whatsapp+8613165183070
Rubber Conveyor Belt Frame Type Vulcanizing Machine Conveyor belt vulcanizing machine rubber belt splicing vulcanizing p
