C U Z Purlin Roll Forming Machine For Structure Frame
| FOB Price: | 17500.00 - 38800.00 USD/Set |
|---|---|
| Supply Ability: | 10 Set(s) per Month |
| Shipping: | shipping by 40 feet container |
| Payment Terms: | L/C, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hebei in China |
| Packaging Details: | Main machine body is packed by waterproof |
Quick Details
- Type: Steel Frame & Purlin Machine
- After-sales Service Provided: Engineers available to service machinery overseas
- Certification: CE ISO
- Brand Name: ZZ
- Condition: New
- Type: roll forming machine
- Warranty: 18 month
- Weight: 5.8 t
- Dimension(L*W*H): 12.0*1.28*1.5m
- Power(W): 15kw
- Voltage: 380v
- Production Capacity: 15-20m/min
Specifications
Profile Drawings for Reference
Working Flow
De-coiler->Leveling Device->Pre cut->Punching Device (Regular Holes) ->Roller Forming Machine->Hydraulic Cutting Device->Product Stand Tables
Technical Parameter
No. |
Item |
Parameter | |
1 |
Size |
Material Thickness |
0.8-3.0mm |
Product Size |
Width:80 - 300 mm Height: 40 - 80 mm | ||
2. |
De-coiler Specs |
Type |
Passivetype |
Max. Capacity |
3Tons | ||
Coil ID |
508mm | ||
Max. Coil OD |
≤1000mm | ||
Max. Coil Width |
≤300mm | ||
3. |
Machine Specs |
Forming Speed |
6 - 8M/Min |
Forming Stations |
13Stations | ||
Roller Material |
GCr15 Steel | ||
Shaft Diameter |
85mm | ||
Shaft Material |
40Cr | ||
Forming Structure |
Guiding Column | ||
Base Frame |
H-Section Steel Welding | ||
Driven System |
Hydraulic motor | ||
HydraulicMotor Power |
22KW--------------1Set | ||
HydraulicMotor Brand |
TILORMS | ||
Cutting Power |
5KW | ||
Cutting Tolerance |
±2mm | ||
Installation Dimension |
20~25M*2M | ||
Machine Weight |
about 10Tons | ||
4. |
Computer Box |
PLC |
Delta |
Frequency Converter |
Delta | ||
Encoder |
Omron | ||
Touch Screen |
10 inch | ||
Button |
Emergency Stop | ||
5. |
Paint |
Base Paint |
Anti-rust |
Surface Paint |
as customer's Request | ||
6. |
Others |
Electric motor overloads protection | |
Short circuit protection | |||
380V/50HZ/3Phase(depend on clients' need ) | |||
