Union Spring(Shenzhen) Technology Co., Ltd.
China Manufacturer with main products: 3D Wire Bending Machine, CNC Spring Machine, Camless Spring Machine, Spinner, Temper Furnace, Wire Rotating Spring Forming Machine |
3-8mm Metal Computer Bracket Bending Equipment
| FOB Price: | 45000.00 - 50000.00 USD/Piece |
|---|---|
| Supply Ability: | 10 Piece(s) per Week |
| Shipping: | by sea |
| Payment Terms: | T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe |
|---|---|
| Place of Origin: | CHINA |
| Packaging Details: | WOODEN BOX |
Quick Details
- After-sales Service Provided: Engineers available to service machinery overseas
- Condition: New
- Brand Name: union spring
- Weight: 2600kg
- color: grey and red
- Model Number: US-3D708
- wire diameter: 3-8mm
- warranty: 1 year
- Voltage: 380V
Specifications
Machine description:
1. the 3D wire bending machine adopts Taiwan computer control system and Japanese servo motor, which is independently controlled by several sets of servomotors, with powerful expansibility and features of convenient, fast, high speed and high precision.
2. the computer startup and shutdown speed is fast, interface language can switch between Chinese and English, easy to operate.the computer interface can adjust the speed while producing, and the production speed is more than 25% higher than that of domestic counterparts.
3. Bearing, gear, guide rail and other important parts are imported accessories.Protective device anti - collider, composite tool to complete all procedures, quality is guaranteed and less wearing parts.
4. High precision, can do wire forming products within the range of 3.0-12mm wire diameter, the error is reduced to 0.1mm. the use of the automatic wire feeder allows the machine to change the wire operation more convenient.
5, the machine is mainly used in the auto parts industry; pet cage accessories; garden tool accessories; electronic and electrical products forming; toy accessories forming; sports equipment accessories forming; kitchen and bathroom pendant hardware forming; handicraft forming; supermarket shelf accessories forming and other types of metal wire forming field.
Model |
US-3D806 |
US-3D708 |
US-3D710 |
Axis |
8 |
7 |
7 |
Wire Diameter |
3-6 mm |
4-8 mm |
5-10 mm |
WireWheel Sets |
2 sets |
3 sets |
3 sets |
WireFEedingAxis |
2.7KW |
4.5KW |
4.5KW |
Rotary WireAxis |
2.0KW |
2.0KW |
2.7KW |
CUttingAxis |
2.0KW |
2.7KW |
5.5KW |
ExternalTOrsionAxis |
2.0KW |
2.7KW |
4.5KW |
InternalTOrsionAxis |
2.0KW |
2.7KW |
5.5KW |
TorsionHeadLiftAxis |
1.0KW |
1.2KW |
2.0KW |
PlatformLIftingAxis |
0.75KW |
0.75KW |
1.0KW |
WireBox FOrward/BAckwardAxis |
2.7KW |
/ |
/ |
MachineSize |
2650*1250*1750mm3
|
3400*1400*1700mm3 |
3800*1500*1700mm3 |
MachineWeight |
2200kg |
2400kg |
2600kg |
