Millionsun Energy Co., Ltd.

China Manufacturer with main products: Solar Water Heater, Solar Collector, Water Heater Storage Tank, Solar Street Light, Solar Ceiling Light, Heat Pump Water Heater

Home >Products Catalog > Solar light > Energy Saving Solar Panel LED Ceiling Light

Energy Saving Solar Panel LED Ceiling Light

Supply Ability:	6,000 Set(s) per Month
Shipping:	shenzhen
Payment Terms:	L/C, T/T

Inquiry Now

Related products from verified members

Product Details

Export Markets:	South America, Eastern Europe, Africa, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	wooden case

Quick Details

Work Time (h): 50000
Solar Power (W): 18
Application: Home
Specification: Normal
Brand Name: Millionsun
Load Power (W): 18
Output Voltage (V): 26
Model Number: MS-R300/1200L
Power Supply Modes: Solar panel power
Solar panel: 18W / 26V
Lighting Mode: Automatic light-on at sunny daytime
Light Color: White
Installation: Flush mounted / surface mounted
Light Source: Bridgelux 2835
Sensor: Detection angle: 140
IP Rating: IP44
Efficiency: 80 LM/W
Luminous Flux: 1200 LM

Specifications

Product Description

What is a Solar LED Skylight?
Combining modern solar technology with advanced LED technology, this is a green new lighting solution. A break through to the traditional daylighting way ( tubular skylight / sky tube), coming out to realize a much more convenient, longer lasting & energy efficient day & night lighting.
A Better Replacement of Conventional Tubular
Skylight with the same function as a tubular skylight, the solar LED skylight can make up for poor natural daylighting, brighten every dark space with no outside windows.but it definitely saves more for you both on installation and maintenance, as it needs no holes, shafts, domes..Instead,it could be perfectly done with a solar panel,a cable and an energy-efficient LED panel light!

New Solar LED SkylightVSConventional Tubular Skylight

7" NOs" from New Solar LED Skylight

No destruction to existing building
No tube or light shaft to install
No limit by the installation position
No bugs collecting in the light diffuser
No heat or UV transfer
No water leakage
No hail worries

the obvious feature of the solar LED skylight is to work under nature's free solar energy and no need power consumption from grid electricity. but it is more than that. We aim to bring you an unprecedented lighting experience given by more upgraded solar LED skylight systems.

Here comes our Solar LED Skylight System:

System	System A	System B	System C	System D
Power Supply	Powered by solar panel	Rechargeable solar battery (1 circuit)	Solar panel and battery backup (2 circuits)	Solar panel and grid power as backup (2 circuits)
Lighting Feature	with a similar experience to a taditional skylight, provide natural solar day lighting, let you perceive the outdoor sunlight Fromthe indoor solar skylight.	Offer free solar smart day & night lighting with radar induction	Offer day & night lighting. Give smart radar sensor lighting when battery power is involved	Offer day & night lighting. Give smart radar sensor lighting when grid power i5 involved
Version	/	Upgraded	Upgraded	Upgraded
Constitute	Solar panel + light fixture	Solar panel + battery + light fixture + radar sensor	Solar panel + light fixture + battery backup + radar sensor	Solar panel + light fixture + grid power backup + radar sensor
Lighting time	the light keeps on when the sunlight is available	at day or night, the light is automatically on when people is there, off when people left.	in sunny daytime,the light keeps on;in sunless time, it turns into sensor smart lighting (automatically on when people is there, off when people left).	in sunny daytime,the light keeps on;in sunless time, it turns into sensor smart lighting (automatically on when people is there, off when people left).

Features

Good Light Source: Top grade SMD2835 LED, no UV, no leak, no flicker, minimal heat or decay, make long lasting & energy-efficient lighting performance. Ldeal Power Supply Modes:Green energy power supply by polycrystalline solar panel, multi power supply modes available.2.Day & Night Lighting: When with backup power, the solar LED skylight system keeps lighting at day and night, for both daily and emergency use,
Smart Solar Lighting: Smart controller included, make automatic switchover to backup energy & turn into radar sensor smart lighting mode for sunless periods, not waste a shred of backup power.
Green Environmental Kit: Solar LED skylight works with green solar energy, allowing savings of up to 90%,as an environmentally friendly kit with no carbon emissions.
User Friendly Easy to Install: Quick and easy DIY installation for verious ceiling types, no light shafts, no structural changes, just one plug-in action on wiring, maintenance free.

Benefits

1.Save Money
Powered by solar panel without electric bills
Energy-efficient LED light source
Low installation & maintenance cost
2.Save Trouble
Easy and fast installation without light shaft
Hands free smart lighting by radar sensor
Quality assurance with long lifespan & low maintenance
3.Save Worries
Perfectly light up dark spaces where natural light is unavailable
Considerate & safe sensor lighting at dark night
Continuously light at night / once blackout with backup power

Application

Solar LED Skylights with light fixtures of simple style, flush mounting, suit all kinds of ceiling installation, for integrated ceiling, wooden ceiling, or plaster ceiling.

System	Lighting Modes	Applications
System A	Keep on as per the sunlight	Good in making up for poor natural daylighting
System B	Light-on when someone comes,light-off whey theyve left	Residential hallway, stairs,bathroom,etc.
System C	in sunny daytime, the lightis on;in sunless time, light-on when someone comes, light- off whey they've left	Residential/Commercial hallway,stairs, washroom,etc.
System D		High frequency use places( features saving energy from long- term lighting )

Technical specifications

Model	MS-R300/1200L	MS-R300/2200L	MS-S300/1200L	MS-S300/2200L	MS-S300x600/2200L
Light Fixture	LED panel light, round dia.300x12mm, 1 PC	LED panel light, round dia.300x12mm, 1 PC	LED panel light, Square 300x300mm, 1pc	LED panel light, Square 300x300mm, 1pc	LED panel light, Square 300x300mm, 1pc
Power Supply Modes	Solar panel power	Solar panel power	Solar panel power	Solar panel power	Solar panel power
Solar Panel	18W / 26V	30W / 26V	18W / 26V	30W / 26V	30W / 26V
Lighting Mode	Automatic light-on at sunny daytime	Automatic light-on at sunny daytime	Automatic light-on at sunny daytime	Automatic light-on at sunny daytime	Automatic light-on at sunny daytime
Cable	10m cable to connect solar panel & light	10m cable to connect solar panel & light	10m cable to connect solar panel & light	10m cable to connect solar panel & light	10m cable to connect solar panel & light
Package	480x340x60MM	680x340x60MM	480x340x60MM	680x340x60MM	680x340x60MM
Light Performance
Light Color	White	White	White	White	White
Installation	Flush mounted / surface mounted	Flush mounted / surface mounted	Flush mounted / surface mounted	Flush mounted / surface mounted	Flush mounted / surface mounted
Light Source	Bridgelux 2835	Bridgelux 2835	Bridgelux 2835	Bridgelux 2835	Bridgelux 2835
IP Rating	IP44	IP44	IP44	IP44	IP44
Efficiency	80 LM/W	88 LM/W	80 LM/W	88 LM/W	88 LM/W
Luminous Flux	1200 LM	2200 LM	1200 LM	2200 LM	2200 LM
Beam Angle( )	120	120	120	120	120
CRI (Ra>)	Ra>85	Ra>85	Ra>85	Ra>85	Ra>85
Area Suitability	5m2	5m2	5m2	5m2	5m2
Color Temperature	4500K	4500K	4500K	4500K	4500K
Operating Temperature	-20℃ to +40℃	-20℃ to +40℃	-20℃ to +40℃	-20℃ to +40℃	-20℃ to +40℃
Lifespan	50000 hours	50000 hours	50000 hours	50000 hours	50000 hours
Lamp Body Materia	Aluminum 6063 housing + PC cover	Aluminum 6063 housing + PC cover	Aluminum 6063 housing + PC cover	Aluminum 6063 housing + PC cover	Aluminum 6063 housing + PC cover
Wire Length	200MM	200MM	200MM	200MM	200MM
Warranty	LED Panel	5
	Solar Panel	15
	AC/DC Power Adapter	5
	Lithium Battery	2

Warranty Details: 5 years warranty for light
