ABOT SVC Servo Controlled Voltage Regulator Stabilizer 15KVA AVR
| FOB Price: | 400.00 - 600.00 USD/Set |
|---|---|
| Supply Ability: | 1,000 Set(s) per Month |
| Shipping: | SEA |
| Payment Terms: | T/T, Western Union |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | film packing, then with exporting wooden box |
Quick Details
- Phase: Three Phase
- Usage: SVC
- Brand Name: ABOT
- Warranty: 18 months
- Model Number: SVC-10KVA
- Input Voltage: 304V-456V
- Output Voltage: 380V+/-2%
- Accuracy: +/-2%
- Current: 23A
- Frequency: 50/60hz
Specifications
Brief Introduction:
SVC series single and three phase full automatic AC voltage regulator is made of contact type auto regulator, servo motor and auto controlled circuit. When the voltage is unstable or load changes, the auto control system will send signal to start servo motor, to let output voltage adjust to rated value and stable voltage.
Technical Parameters
Input |
Voltage |
380V ±20% |
Frequency |
50Hz/60Hz | |
Output |
Rated Voltage |
380V±2% |
Accuracy |
±(1~5)% optional (±2% general setting) | |
Response Time |
<1s | |
Waveform Distortion |
No additional waveforms generated (static) | |
Efficiency |
≥98% | |
Overload Ability |
150%(60min) 300%(10min) | |
Relative Humidity |
20%~90% | |
Seismic Coefficient |
0.3G | |
Ground Clearance |
>8mm | |
Ground Resistance |
0.1Ω | |
Heat Resistance of Wire |
Level H, 180℃ | |
Noise |
≤55dB | |
Cooling System |
fan | |
Product Dimensions
Model |
Capacity (KVA) |
Power (KW) |
Phase |
Input |
Output |
Current(A) |
Size(mm) L*W*H |
Weight(KG) |
SVC-3009 |
6 |
4.8 |
3 |
380V±20% |
380V±(1-5)% |
9 |
500*350*480 |
28 |
SVC-3010 |
10 |
8 |
15 |
500*350*480 |
36 | |||
SVC-3015 |
15 |
12 |
23 |
500*400*730 |
80 | |||
SVC-3020 |
20 |
16 |
30 |
500*400*730 |
90 | |||
SVC-3030 |
30 |
24 |
45 |
500*400*730 |
105 | |||
SVC-3040 |
40 |
32 |
60 |
610*480*850 |
150 | |||
SVC-3050 |
50 |
40 |
76 |
500*400*730 |
160 | |||
SVC-3060 |
60 |
48 |
91 |
500*400*730 |
180 | |||
SVC-3080 |
80 |
64 |
121 |
660*510*1120 |
220 | |||
SVC-30100 |
100 |
80 |
152 |
660*510*1120 |
240 |
FAQ
Q1, Are you a manufacturer or a trading company?
Re: We are an original manufacturer working from design, production to sell, specializing in various voltage regulator stabilizer, transformer, UPS and solar inverter for more than 11 years.
Q 2, what's the payment terms?
Re: We accept T/T, PayPal, Western Union, Alipay.
Q 3, What is your standard of packaging?
Re: for the small capacity voltage regulator stabilizer/transformer/UPS/solar inverter, we will use carton, for big capacity products, we shall use strong wooden case for good protection.
Q 4, Can you accept OEM /ODM?
Re: Yes, we welcome OEM/ODM orders for Voltage regulator stabilizer/transformer/UPS/solar inverter. We offer customer with customized products, as we have strong R&D team with 5 experienced engineers to meet kinds of custom requirements.
Q 5, how's the delivery time ?
Re: Usually it will take about two weeks for production, also depending on the order quantity. VOltage regulator stabilizer/transformer/UPS/solar inverter.
Q 6, how do you control quality?
Re: We have QC to inspect the goods during materials coming, production, and packaging. 100% full inspection is guaranteed before delivery.
Q 7, What's your shipping method?
Re: We are in Shenzhen, near to Hong Kong. All shipments are convenient here. International express (TNT, UPS, DHL and FedEx), by air and by sea. We always compare at least 3 shipping costs before decision.
