| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | Export standard carton with reinforced plywood outside |
Quick Details
- Brand Name: ZYBAYI
- Type: Ultrasonic Sterilization Equipments
- Rating: 60W
- Voltage: 220V/50Hz
- Condition: OEM
- Model Number: K3
- UVC disinfection: Plasma disinfection
- HEPA filter purification: Activated carbon filter purification
- Nano dry atomization spraying: Fine filter purification
- Automatic navigation: Automatic obstacles avoidance
- Automatic charging: Automatic disinfectant refilling
Specifications
Product parameters | ||
Structure | ||
Height |
1350mm(Lifting Rod to highest 1700mm) | |
Width(Diameter) |
420mm | |
Universal wheel |
2Inches | |
Driving Wheel |
6-inch rubber wheel | |
Turning radius |
260mm | |
Main structural material |
ABS(plastic), Aluminum Alloy | |
Weight |
45kg-50kg(Fully loaded) | |
MaxWeight-Bearing |
55kg | |
MOvementPerformance | ||
MaximumMovingSpeed |
0.8 M/s | |
Maximum Obstacles-overcoming height |
10mm | |
Maximum ridge-overcomingWidth |
20mm | |
Maximum climbing angle |
15 | |
Disinfection module parameters | ||
UV Sterilization lamp |
285Quartz Tube15W*4 LED-UVC*2lines | |
Ultrasonic atomization |
3L/hour | |
Plasma generator |
Positive ion concentration800millionPCS/cm3 Anion concentration1200MillionPCS/cm3 | |
DisinfectantCapacity |
10L | |
Purification module parameters |
||
Air filtration |
PArticulates260m3/H Formaldehyde100m3/H | |
Navigation module performance | ||
Map Resolution |
5cm | |
Navigation accuracy |
2~8cm | |
PRocessor |
INTEL I5 | |
RAM |
4G | |
HArd disk |
SSD64G | |
Sensor parameters | ||
Lidar |
EAI G4 High precision lidar | |
Obstacle avoidance sensor |
Ultrasonic module *5 | |
Anti-drop Sensor |
None | |
IMUModule |
Incl: MEMS gyroscope, 3-axis accelerometer, and signal processing circuit | |
Battery and endurance | ||
Battery type |
Power Lithium battery | |
BAttery capacity |
12Ah/24V | |
Charging Time |
Approx5hours | |
Charging voltage |
29.4V | |
CHarging current |
3A | |
Protective function |
OverloadCurrent, over discharge, short circuit protection | |
Standby Power consumption |
25W | |
No-load batteryDuration |
Approx6hrs | |
Charging Pile | ||
Auto recharge |
Support | |
Direct charge |
Support | |
Charging Time |
Approx 5 hrs | |
Motor | ||
Motor type |
Brushless DC hub motor | |
Nominalpower |
600w | |
Reduction Ratio |
30 | |
WOrking Environment | ||
WorkingTemperature |
-10~45℃ | |
Working humidity |
30%~70% | |
Connector | ||
PowerConnector |
24V | |
Hardware connector |
Network Port,USBport | |
Software interface |
SDKdEvelopmentkit | |
