Home >Products Catalog > Sinotruk 60t Tri Fuwa/BRW Axles Heavy Duty Gooseneck Low Bed Semi Trailer

Sinotruk 60t Tri Fuwa/BRW Axles Heavy Duty Gooseneck Low Bed Semi Trailer

FOB Price:	1.00 - 10000.00 USD/Unit
Supply Ability:	500 Unit(s) per Month
Shipping:	bulk ship, container ship
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Packaging Details:	nude

Quick Details

Use: Truck Trailer
Brand Name: SCEC
Max Payload: 60t
Size: 13000x2300x1650mm
Material: Steel
Use: Low bed Trailer for heavy equipment
Type: Semi-Trailer
Product name: Low bed semi trailer
Curb Weight(KG): 10t
Axle Brand: 13t Fuwa axle
Tire Type and quantity: 12.00R20, 12pcs

Specifications

Sinotruk 60t Tri Fuwa/BRW Axles HeavyDutyGOoseneck Low Bed Semi Trailer with Mechanical Ladder for Heavy Machinery Transport

Features ofSinotruk 60t Tri Fuwa/BRW Axles HeavyDutyGOoseneck Low Bed Semi Trailer

1. Low flat

the series of low-bed semi-trailers have flat, recessed beam and exposed tire structures. the longitudinal beams are straight or gooseneck. the frame is stepped, and the longitudinal beam section is I-shaped, with high rigidity and high strength.

2. Cargo platform

the main plane of the frame cargo platform is low, which ensures the stability of transportation and is suitable for carrying various types of engineering machinery, large equipment and steel.

3. Three-axis balanced

It adopts three-axis balance type, two-axis balance type or rigid suspension. Mass balancer is installed between the front and rear leaf springs, which can change the deflection of the front and rear leaf springs by the same amount, and make the front and rear axles balanced.

the low flatbed semi-trailer series products are suitable for the transportation of various steel materials such as a variety of machinery and equipment, large objects, highway construction equipment, large tanks, and power station equipment. the entire vehicle adopts advanced computer-aided design software, which is optimized for flexible and diverse designs. According to user requirements, the frame bearing surface is designed to meet the transportation of various special goods.

Parameters ofSinotruk 60t Tri Fuwa/BRW Axles HeavyDutyGOoseneck Low Bed Semi Trailer

Product Name	heavy duty gooseneck excavator low bed lowbed lowboy truck semi trailers for sale
Dimension(Lx W x H)(mm)	13000 x 3000 x 1650
Curb Weight(KG)	10000
Loading Weight( KG)	60000
Departure Angle	16
Axle Brand	13TON Axle FUWA Brand
Axle Number	3
Suspension system	Mechanical suspension
Gooseneck and Ladders	Standard
Steel Spring	10/10/10 leaf spring
Frame	the height of the beam is 500mm, upper plate is 16mm, down plate is 18mm, middle plate is 10mm.
Platform plate	6mm Diamond Plate
Tire Type and quantity	12R22.5 12units Chinese brand
Traction Pin	50mm or 90mm JOST brand
Spare Wheel Bracket	2 pieces
Tool Box	1 Unit
Landing Leg	JOST 28T load landing leg
Brake system	Dual Line braking system (ABS optional)
Brake air chamber	6 big air chambers
Electrical system	24V,7 Pole plug
	Tail lamp with turn signal, brake light & reflector, side lamp etc.
	One set 6-core standard Cable.
Side Guard	None
Painting	Color by customer's requirement
Packing	Polish with wax before shipping
Delivery way	Transfer to China port, and carry by bulk ship, the freight cost depends on the volume.

Sinotruk 60t Tri FuwaBRW Axles Heavy Duty Gooseneck Low Bed Semi Trailer

after-sales Service

1: Our company promise a one-year warranty period, during this period, under normal use if there is damage to the accessories, we will provide our customers with free new accessories.

2: Operational problems, technical configuration issues, etc., We will promptly provide feasible solutions for our customers. We are investing in the construction of a number of foreign service department, will be better to serve the global customers.

3: We are serious about after-sales service.

Shipping Way

Mode of transport: bulk cargo, ro-ro transport, container transport
We can arrange the most cost-effective transportation solution according to the number of semi-trailers required by customers.
